DEBIX Infinity User Manual page 11

PCIe
40-Pin
Double-Row
Headers
Slot
DIP Switch
Power Supply
Power Input
Mechanical & Environmental
Size (L x W)
Weight
Operating Temp.
www.debix.io
(DWN_USB1 can be configured as USB TOG via software)
1 x USB 2.0 PWR, the connector is Type-C interface for DC 5V

power input
1 x PCIe, support PCIe x1, 19Pin 0.3mm Pitch FPC socket
Default: 3 x UART, 2 x SPI, 2 x I2C, 2 x CAN, 6 x GPIO, which can

be configured to I2S, PWM, SPDIF, GPIO, etc. via software
5V power supply, system reset, ON/OFF

1 x Micro SD slot
1 x DIP Switch
DC 5V/3A
85.0mm x 56.0mm
46g
Industrial grade: -20°C~70°C

Industrial grade: -40°C~85°C

Polyhex Technology Company Limited
11 / 79
