DEBIX Infinity User Manual page 21

2 VDD_3V3
3 VDD_1V8
4 DSI_BL_PWM
5 DSI_EN
6 DSI_TP_nINT
7 DSI_I2C_SDA
8 DSI_I2C_SCL
9 GPIO1_IO14
10 GND
11 DSI_DN0
12 DSI_DP0
13 GND
14 DSI_DN1
15 DSI_DP1
16 GND
17 DSI_CKN
18 DSI_CKP
19 GND
20 DSI_DN2
21 DSI_DP2
22 GND
23 DSI_DN3
24 DSI_DP3
25 GND
26 GND
www.debix.io
Polyhex Technology Company Limited
3.3V output
1.8V output
Backlight control signal
LCD enable signal
touch interrupt pin
Touch the clock terminal of I2C (controlled by I2C2)
Touch the clock terminal of I2C (controlled by I2C2)
IO control pin
To Ground
DSI Differential data channel 0 (-)
DSI Differential data channel 0 (+)
To Ground
DSI Differential data channel 1 (-)
DSI Differential data channel 1 (+)
To Ground
DSI Differential Clock Channels (-)
DSI Differential Clock Channels (+)
To Ground
DSI Differential data channel 2 (-)
DSI Differential data channel 2 (+)
To Ground
DSI Differential data channel 3 (-)
DSI Differential data channel 3 (+)
To Ground
To Ground
