DEBIX Infinity User Manual page 10

Storage
Nor Flash
OS
Boot Mode
Communication
Gigabit Network
WiFi & BT
Video & Audio
HDMI
LVDS
MIPI CSI
MIPI DSI
Audio
External I/O Interface
USB
www.debix.io
Micro SD Card (8GB/16GB/32GB/64GB/128GB/256GB optional)

Onboard eMMC (8GB/16GB/32GB/64GB/128GB/256GB optional)

64Mbits Nor Flash (reserved)
Android 11, Ubuntu 20.04, Yocto-L5.10.72_2.2.0, Windows 10 IoT
Enterprise
NOTE
DEBIX Infinity with 4GB LPDDR4 (recommended 8GB LPDDR4)
supports Windows 10 IoT Enterprise
Boot from Micro SD Card (default)

Boot from eMMC

Boot from Nor Flash

2 x 10/100/1000M Ethernet interfaces

 1 x RJ45, support POE power supply (need POE power
supply module)
 1 x RJ45 (POE power supply not supported)
2.4GHz & 5GHz dual-band WiFi, BT 5.0, external WiFi&BT SMA
antenna(IPEX-1) connector
1 x HDMI output, the connector is Type A HDMI female
1 x LVDS output, single & dual channel 8 bit, 2 x 15Pin double-row pin
headers
1 x MIPI CSI, support 4-lane, 24Pin 0.5mm Pitch FPC socket
1 x MIPI DSI, support 4-lane, 24Pin 0.5mm Pitch FPC socket
1 x 3.5mm headphone and microphone combo port
2 x USB 3.0 Host, the connector is double layer Type-A interface

Polyhex Technology Company Limited
10 / 79
