11 SAI2_RXC
13 SAI2_MCLK
15 GND
17 VDD_1V8
19 VDD-5V

2.2.3. Slot

DEBIX 4G board provides a Micro SIM card slot for inserting a SIM card to provide network
connection and data transmission for the 4G module.

2.2.4. LED

DEBIX 4G Board has a 4G operation status indicator as shown below:
www.debix.io
Polyhex Technology Company Limited
12
14
16
18
Figure 5 Micro SIM Slot
SAI2_RXFS
GND
GND
VDD_3V3
