DEBIX Infinity User Manual page 72

Send and Receive: Type the test string in the input box of the cutecom window, press
4.
Enter to send, and you can receive the same message in the receive box, as shown in
the following figure:
4.13. Usage of CAN
DEBIX Infinity has two CAN communication interfaces. The CAN interface needs to be used
in conjunction with a CAN transceiver peripheral for CAN communication, such as the DEBIX
I/O Board, or other CAN transceiver modules.
Table 17 Pin definition of CAN
Function Interface
CAN
For CAN verification, refer to the CAN verification description of the
www.debix.io
Figure 71 UART self-sending and self-receiving
Pin
31
33
J2
35
37
Polyhex Technology Company Limited
Definition
CAN1_TXD
CAN1_RXD
CAN2_TXD
CAN2_RXD
Device Node
can0
can1
DEBIX I/O Board.
