25 GND
26 GND
27 LVDS1_CLK_N
28 LVDS1_CLK_P
29 LVDS1_TX3_N
30 LVDS1_TX3_P

2.3.4.3. MIPI DSI Interface

DEBIX Infinity provides one MIPI DSI interface (J13) with a 2*12Pin/0.5mm FPC socket
connector, which can be used to connect a MIPI display touch screen.
Key features of MIPI DSI include:
MIPI DSI compliant with MIPI-DSI standard V1.2, compatible with standard specification

V1.01r11
The commonly used MIPI DSI resolutions are supported as follows:

 1080 p60, WUXGA (1920x1200) at 60 Hz, 1920x1440 at 60 Hz, UWHD (2560x1080)
at 60 Hz
 Maximum resolution up to WQHD(2560x1440), it depends on bandwidth between
input clock (video clock) and output clock (D-PHY HS clock)
 Support 1, 2, 3 or 4 data lanes
 Support pixel format: 16bpp, 18bpp packed, 18bpp loosely packed (3 bytes format),
24bpp.
Interface

 Compliant with Protocol-to-PHY Interface (PPI) at 1.0Gbps/1.5Gbps MIPI DPHY
 Support RGB interface for video image input from general display controller.
www.debix.io
Polyhex Technology Company Limited
To Ground
To Ground
LVDS1 Clock differential signal path (-)
LVDS1 Clock differential signal path (+)
LVDS1 Differential data channel 3 (-)
LVDS1 Differential data channel 3 (+)
