The pin sequence is shown in the figure:
The MIPI DSI interface is defined as follows:
Table 7 Pin definition of MIPI DSI
Pin
Definition
1
SW_VDD5V
www.debix.io
Figure 12 MIPI DSI
Figure 13 Pin sequence of MIPI DSI
Description
5V output
Polyhex Technology Company Limited
20 / 79
