Table 9 Pin definition of PCIe
Pin Definition
1 VDD_3V3
2 VDD_5V
3 VDD_1V8
4 GND
5 GND
6 GND
7 SAI2_MCLK
8 SAI2_RXFS
9 SAI2_RXC
10 GND
11 PCIE_CLKN
12 PCIE_CLKP
13 GND
14 PCIE_TXN
15 PCIE_TXP
16 GND
17 PCIE_RXN
18 PCIE_RXP
19 GND

2.3.8. GPIO

DEBIX Infinity has a set of 2*20Pin/2.0mm GPIO interface (J2), which can be used for
external hardware such as LED, button, sensor, function modules, etc.
The voltage of I2C, UART, CAN, SPI, GPIO pin is 3.3V.

5V pins (pin6, pin8) can be used to power to DEBIX Infinity or peripherals.

www.debix.io
Polyhex Technology Company Limited
CPU PAD/Pin
-
-
-
-
-
-
AJ15
AH17
AJ16
-
E16
D16
-
B15
A15
-
B14
A14
-
