Codan Envoy Control Getting Started Manual page 172

I
NSTALLING THE TRANSCEIVER
O
VERVIEW OF MOBILE STATIONS
Connecting the control cable to an automatic tuning antenna
To connect the control cable to an antenna:
1
1
Connecting the power supply
To connect the transceiver to the battery power supply:
1
1
1
1
1
160
Connect the socket at the end of the cable (Codan part number
08-05627-00x) into the plug at the base of the antenna, then
secure the locking ring tightly into position.
Fit the plug at the opposite end of the cable (Codan part
number 08-05627-00x) into the socket at the end of the lead
from the RFU.
If you are using a 24 V battery supply, connect the battery to a
24 V to 12 V voltage regulator (Codan part number 15-00508).
Connect the power supply cable (Codan part number 08-03255)
to the plug at the end of the 12 V cable lead from the RFU.
Route the power supply cable according to the instructions
supplied with the Vehicle Installation Kit (Codan part number
15-00112).
Insert the 32 A fuse and holder in the power supply cable at a
convenient location, as close as possible to the battery terminals.
Connect the power supply cable to the battery terminals, black to
negative, red to positive.
