SET COMMUNICATION:

This section define the fundamental communication parameters of two buses, SNMP and PROFIBUS.
By Pressing the "Set Communication" button from the main window for SW67177 (Fig. 2) the window
"Set Communication" appears (Fig. 3).
The window is divided in two sections, one for the SNMP Manager and the other for the PROFIBUS
Slave.
The means of the fields for "SNMP Manager" are:
In the field "IP ADDRESS" insert the IP address that you want to give to the Converter;
In the field "SUBNET Mask" insert the SubNet Mask;
In the field "GATEWAY" insert the default gateway that you want to use. This feature can be
enabled or disabled pressing the Check Box field. This feature is used for going out of the net;
In the field "SNMP Name of
The means of the fields for the "PROFIBUS Slave" section are:
In the field "ID Device" the PROFIBUS Slave ID is defined.
In the field "Baudrate" the PROFIBUS Slave baudrate is defined (fixed to Auto Baudrate).
In the field "Number Byte
244 bytes);
In the field "Number Byte
max 244 bytes).
ADFweb.com Srl – IT31010 – Mareno – Treviso
Station" is possible to assign a name to the SNMP node.
IN" the number input bytes of PROFIBUS Slave is defined (at max
OUT" the number output bytes of PROFIBUS Slave is defined (at
User Manual PROFIBUS Slave / SNMP Manager
Document code: MN67177_ENG Revision 1.000
Figure 3: "Set Communication" window
