Industrial Electronic Devices
User Manual
Revision 1.000
English
CAN / SNMP Manager - Converter
(Order Code: HD67171-A1, HD67171-B2)
for Website information:
www.adfweb.com?Product=HD67171
for Price information:
www.adfweb.com?Price=HD67171-A1
www.adfweb.com?Price=HD67171-B2
Benefits and Main Features:
Very easy to configure
Electrical isolation
Temperature range: -40°C/85°C (-40°F/185°F)
User Manual
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual CAN / SNMP Manager
Document code: MN67171_ENG
For others SNMP Manager products, see also the following links:
Converter SNMP to
www.adfweb.com?Product=HD67B47
www.adfweb.com?Product=HD67D40
www.adfweb.com?Product=HD67E24
www.adfweb.com?Product=HD67041
www.adfweb.com?Product=HD67092
www.adfweb.com?Product=HD67156
www.adfweb.com?Product=HD67159
www.adfweb.com?Product=HD67160
www.adfweb.com?Product=HD67161
www.adfweb.com?Product=HD67162
www.adfweb.com?Product=HD67163
www.adfweb.com?Product=HD67164
www.adfweb.com?Product=HD67165
www.adfweb.com?Product=HD67166
www.adfweb.com?Product=HD67167
www.adfweb.com?Product=HD67168
www.adfweb.com?Product=HD67169
www.adfweb.com?Product=HD67170
www.adfweb.com?Product=HD67172
www.adfweb.com?Product=HD67173
www.adfweb.com?Product=HD67174
www.adfweb.com?Product=HD67176
www.adfweb.com?Product=HD67177
www.adfweb.com?Product=HD67178
www.adfweb.com?Product=HD67613
www.adfweb.com?Product=HD67693
www.adfweb.com?Product=HD67726
www.adfweb.com?Product=HD67753
www.adfweb.com?Product=HD67820
www.adfweb.com?Product=HD67849
www.adfweb.com?Product=HD67953
www.adfweb.com?Product=HD67986
Do you have an your customer protocol?
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
www.adfweb.com?Cmd=helpme
INFO:
www.adfweb.com
Revision 1.000
Pagina 1 di 30
(OPC UA Server)
(LoRaWAN)
(EtherCAT)
(DMX)
(M-Bus Wireless)
(CANopen)
(EtherNet/IP)
(DeviceNet Master)
(DeviceNet Slave)
(J1939)
(M-Bus Master)
(Modbus Master)
(Modbus Slave)
(Modbus TCP Master)
(Modbus TCP Slave)
(PROFIBUS Master)
(PROFIBUS Slave)
(BACnet Slave)
(CANopen)
(DeviceNet Slave)
(EtherNet/IP)
(Modbus TCP Slave)
(PROFIBUS Slave)
(PROFINET Slave)
(PROFINET)
(BACnet Slave)
(BACnet Master)
(IEC 61850 Server)
(KNX)
(DALI)
(MQTT)
(IO-Link Slave)
Phone +39.0438.30.91.31
Advertisement
Table of Contents
Related Manuals for ADF Web HD67171-A1
Summary of Contents for ADF Web HD67171-A1
- Page 1 Converter SNMP to www.adfweb.com?Product=HD67B47 (OPC UA Server) www.adfweb.com?Product=HD67D40 (LoRaWAN) CAN / SNMP Manager - Converter www.adfweb.com?Product=HD67E24 (EtherCAT) www.adfweb.com?Product=HD67041 (DMX) www.adfweb.com?Product=HD67092 (M-Bus Wireless) (Order Code: HD67171-A1, HD67171-B2) www.adfweb.com?Product=HD67156 (CANopen) www.adfweb.com?Product=HD67159 (EtherNet/IP) for Website information: www.adfweb.com?Product=HD67160 (DeviceNet Master) www.adfweb.com?Product=HD67171 www.adfweb.com?Product=HD67161 (DeviceNet Slave) www.adfweb.com?Product=HD67162 (J1939) www.adfweb.com?Product=HD67163...
-
Page 2: Updated Documentation
User Manual CAN / SNMP Manager Document code: MN67171_ENG Revision 1.000 Pagina 2 di 30 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that Page you need to check that the following document is: INDEX UPDATED DOCUMENTATION Updated... -
Page 3: Security Alert
User Manual CAN / SNMP Manager Document code: MN67171_ENG Revision 1.000 Pagina 3 di 30 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application. -
Page 4: Example Of Connection
User Manual CAN / SNMP Manager Document code: MN67171_ENG Revision 1.000 Pagina 4 di 30 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 5: Connection Scheme
User Manual CAN / SNMP Manager Document code: MN67171_ENG Revision 1.000 Pagina 5 di 30 Industrial Electronic Devices CONNECTION SCHEME: Figure 1a: Connection scheme for HD67171-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... - Page 6 User Manual CAN / SNMP Manager Document code: MN67171_ENG Revision 1.000 Pagina 6 di 30 Industrial Electronic Devices Figure 1b: Connection scheme for HD67171-B2 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
- Page 7 Pagina 7 di 30 Industrial Electronic Devices CHARACTERISTICS: The HD67171-A1 and HD67171-B2 is a CAN / SNMP Manager - Converter. It has the following characteristics: Up to 1024 bytes in reading and 1024 bytes in writing; Triple isolation between CAN - Power Supply, CAN - Ethernet, Power Supply - Ethernet.
-
Page 8: Power Supply
The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below. Vmin Vmax Vmin Vmax Consumption at 24V DC: Device Consumption [W/VA] HD67171-A1 HD67171-B2 Caution: Not reverse the polarity power HD67171-A1 HD67171-B2 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com... -
Page 9: Function Modes
User Manual CAN / SNMP Manager Document code: MN67171_ENG Revision 1.000 Pagina 9 di 30 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the ‘Dip1 of Dip-Switch A’: The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device. The second, with ‘Dip1 of Dip-Switch A’... - Page 10 User Manual CAN / SNMP Manager Document code: MN67171_ENG Revision 1.000 Pagina 10 di 30 Industrial Electronic Devices LEDS: The devices has got four (five for HD67515-B2) LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state...
- Page 11 SNMP: The SNMP connection must be made using Connector5 of HD67171-A1/B2 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To connect the device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC/other is recommended the use of a cross cable.
- Page 12 User Manual CAN / SNMP Manager Document code: MN67171_ENG Revision 1.000 Pagina 12 di 30 Industrial Electronic Devices CAN: For terminate the CAN line with a 120Ω resistor it is necessary that the Dip1 of ‘Dip-Switch C’ is at ON position. Cable characteristics: DC parameter: Impedance...
- Page 13 User Manual CAN / SNMP Manager Document code: MN67171_ENG Revision 1.000 Pagina 13 di 30 Industrial Electronic Devices USE OF COMPOSITOR SW67171: To configure the Converter, use the available software that runs with Windows called SW67171. It is downloadable on the site www.adfweb.com and its operation is described in this document.
-
Page 14: New Configuration / Open Configuration
User Manual CAN / SNMP Manager Document code: MN67171_ENG Revision 1.000 Pagina 14 di 30 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a Programmable “CAN / SNMP Manager - Converter”... -
Page 15: Software Options
User Manual CAN / SNMP Manager Document code: MN67171_ENG Revision 1.000 Pagina 15 di 30 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. - Page 16 User Manual CAN / SNMP Manager Document code: MN67171_ENG Revision 1.000 Pagina 16 di 30 Industrial Electronic Devices In the section “Software Settings”, it is possible to enable/disable some keyboard’s commands for an easier navigation inside the tables contained in the different sections of the software.
-
Page 17: Set Communication
User Manual CAN / SNMP Manager Document code: MN67171_ENG Revision 1.000 Pagina 17 di 30 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, SNMP and CAN. By Pressing the “Set Communication” button from the main window for SW67171 (Fig. 2) the window “Set Communication”... -
Page 18: Set Snmp Access
User Manual CAN / SNMP Manager Document code: MN67171_ENG Revision 1.000 Pagina 18 di 30 Industrial Electronic Devices SET SNMP ACCESS: Figure 4: “Set SNMP Manager Access” window By Pressing the “SNMP Manager” button from the main window for SW67171 (Fig. 2) the window “Set SNMP Manager Access” appears (Fig. - Page 19 User Manual CAN / SNMP Manager Document code: MN67171_ENG Revision 1.000 Pagina 19 di 30 Industrial Electronic Devices In the field “Num Bytes” it is possible to select define the dimension of the SNMP data; In the field “Conversion” it is possible to select the conversion to apply to the data read/written from/to the SNMP Manager; If the field “Cancel”...
-
Page 20: Receive Frames
User Manual CAN / SNMP Manager Document code: MN67171_ENG Revision 1.000 Pagina 20 di 30 Industrial Electronic Devices RECEIVE FRAMES: By pressing the “Receive Frames” button from the main window for SW67171 (Fig. 2) the “Receive CAN Frames” window appears (Fig. 5). The COB inserted in this table contains the Output data of SNMP. - Page 21 User Manual CAN / SNMP Manager Document code: MN67171_ENG Revision 1.000 Pagina 21 di 30 Industrial Electronic Devices In the field “Byte7” insert the byte of the SNMP array where saving 7th byte of the CAN message; In the field “Byte8” insert the byte of the SNMP array where saving 8th byte of the CAN message; In the field “Mnemonic”...
-
Page 22: Send Frames
User Manual CAN / SNMP Manager Document code: MN67171_ENG Revision 1.000 Pagina 22 di 30 Industrial Electronic Devices SEND FRAMES: By pressing the “Send Frames” button from the main window for SW67171 (Fig. 2) the “Send CAN frames” window appears (Fig. 6). The COB inserted in this table contains the data received from SNMP side. - Page 23 User Manual CAN / SNMP Manager Document code: MN67171_ENG Revision 1.000 Pagina 23 di 30 Industrial Electronic Devices In the field “Byte4” insert the byte of the SNMP array where taking 4th byte of the CAN message; In the field “Byte5” insert the byte of the SNMP array where taking 5th byte of the CAN message; In the field “Byte6”...
-
Page 24: Update Device
User Manual CAN / SNMP Manager Document code: MN67171_ENG Revision 1.000 Pagina 24 di 30 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. If you don’t know the actual IP address of the device you have to use this procedure: Turn OFF the Device;... - Page 25 A1/B2 device. Note: When you receive the device, for the first time, you also have to update the Firmware in the HD67171-A1/B2 device. Warning: If Fig. 8 appears when you try to do the Update try these points before seeking assistance: Try to repeat the operations for the updating;...
-
Page 26: Mechanical Dimensions
User Manual CAN / SNMP Manager Document code: MN67171_ENG Revision 1.000 Pagina 26 di 30 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 9a: Mechanical dimensions scheme for HD67171-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... - Page 27 User Manual CAN / SNMP Manager Document code: MN67171_ENG Revision 1.000 Pagina 27 di 30 Industrial Electronic Devices Figure 9b: Mechanical dimensions scheme for HD67171-B2 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31...
-
Page 28: Ordering Informations
B: 4M, 35mm DIN Rail mounting Device Family HD67171: CAN / SNMP Manager - Converter Order Code: HD67171-A1 CAN / SNMP Manager – Converter ( Housing type: A, Terminal Blocks Connectors ) Order Code: HD67171-B2 CAN / SNMP Manager – Converter ( Housing type: B, Terminal Blocks Connectors ) - Page 29 User Manual CAN / SNMP Manager Document code: MN67171_ENG Revision 1.000 Pagina 29 di 30 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.
-
Page 30: Warranties And Technical Support
User Manual CAN / SNMP Manager Document code: MN67171_ENG Revision 1.000 Pagina 30 di 30 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following: Obtain a Product Return Number (PRN) from our internet support at www.adfweb.com.
