In the field "Position" it is possible to select the position where take/save the data from/to the PROFIBUS arrays;
In the field "Num Bytes" it is possible to select define the dimension of the SNMP Data;
In the field "Convertion" it is possible to select the type of data conversion to apply to the data read/written from/to SNMP side;
In the field "Mnemonic" a description of the data inserted in the row is defined.
Note:
If the field "On change" and "On Timer" is checked and the "Poll Time" is different from 0, the converter sends the SNMP writing
request cyclically and also when the data is changed.
Note:
If the "Trap" mode is used, the fields "On CMD", "On Change" and "On Timer" must be disabled.
PROFIBUS GSD:
By pressing the "PROFIBUS GSD" button it is possible to save the GSD file for the PROFIBUS side.
With this feature you can save the configuration of the converter of the PROFIBUS side.
Note:
When you import the .gsd file on your Master PROFIBUS you have to add all the modules that are present inside it.
