Industrial Electronic Devices
User Manual
Revision 1.000
English
RS485 / RS422 - Converter
(Order Code: HD67116-A1)
for Website information:
www.adfweb.com?Product=HD67116
for Price information:
www.adfweb.com?Price=HD67116-A1
Benefits and Main Features:
Very easy to configure
Electrical isolation
Temperature range: -40°C/85°C (-40°F/185°F)
User Manual
ADFweb.com Srl – IT31010 – Mareno – Treviso
Axis Solutions Pvt Ltd is the Authorized Distributor of
www.axisindia.in | info@axisindia.in
User Manual RS485 / RS422 - Converter
Document code: MN67116_ENG
Revision 1.000
For others Converter / Adapter:
RS232 / RS422
See also the following link:
www.adfweb.com?Product=HD67115
RS232 / RS485
See also the following link:
www.adfweb.com?Product=HD67118
USB / RS485
See also the following link:
www.adfweb.com?Product=HD67119
Ethernet / RS232 / RS485
See also the following link:
www.adfweb.com?Product=HD67038
Do you have an your customer protocol?
See the following link:
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
Ask it to the following link:
www.adfweb.com?Cmd=helpme
INFO:
www.adfweb.com
Phone +39.0438.30.91.31
in India
Page 1 of 22
Advertisement
Table of Contents
Related Manuals for ADF Web AXIS HD67116-A1
Summary of Contents for ADF Web AXIS HD67116-A1
- Page 1 User Manual RS485 / RS422 - Converter Document code: MN67116_ENG Revision 1.000 Page 1 of 22 Industrial Electronic Devices User Manual Revision 1.000 English RS485 / RS422 - Converter (Order Code: HD67116-A1) for Website information: www.adfweb.com?Product=HD67116 for Price information: For others Converter / Adapter: www.adfweb.com?Price=HD67116-A1 RS232 / RS422 See also the following link:...
-
Page 2: Table Of Contents
User Manual RS485 / RS422 - Converter Document code: MN67116_ENG Revision 1.000 Page 2 of 22 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that Page you need to check that the following document is: INDEX UPDATED DOCUMENTATION Updated... -
Page 3: Security Alert
User Manual RS485 / RS422 - Converter Document code: MN67116_ENG Revision 1.000 Page 3 of 22 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application. -
Page 4: Example Of Connection
User Manual RS485 / RS422 - Converter Document code: MN67116_ENG Revision 1.000 Page 4 of 22 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 5: Connection Scheme
User Manual RS485 / RS422 - Converter Document code: MN67116_ENG Revision 1.000 Page 5 of 22 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme for HD67116-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 6: Characteristics
User Manual RS485 / RS422 - Converter Document code: MN67116_ENG Revision 1.000 Page 6 of 22 Industrial Electronic Devices CHARACTERISTICS: The HD67116 is a RS485 / RS422 Converter. They have the following characteristics: Triple isolation between RS485 - Power Supply, RS485 – RS422, RS422 - Power Supply; Two-directional information between RS485 bus and RS422 bus;... -
Page 7: Power Supply
User Manual RS485 / RS422 - Converter Document code: MN67116_ENG Revision 1.000 Page 7 of 22 Industrial Electronic Devices POWER SUPPLY: The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below. Vmin Vmax Vmin... -
Page 8: Function Modes
User Manual RS485 / RS422 - Converter Document code: MN67116_ENG Revision 1.000 Page 8 of 22 Industrial Electronic Devices FUNCTION MODES: The device has got two function modes depending on the position of the ‘Dip2 of Dip-Switch A’: The first, with ‘Dip2 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device. The second, with ‘Dip2 of Dip-Switch A’... -
Page 9: Leds
User Manual RS485 / RS422 - Converter Document code: MN67116_ENG Revision 1.000 Page 9 of 22 Industrial Electronic Devices LEDS: The device has got four LEDs that are used to give information about the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state... -
Page 10: Rs485
User Manual RS485 / RS422 - Converter Document code: MN67116_ENG Revision 1.000 Page 10 of 22 Industrial Electronic Devices RS485: For terminate the RS485 line with a 120Ω resistor it is necessary to put ON dip 1, like in figure. The maximum length of the cable should be 1200m (4000 feet). -
Page 11: Rs422
User Manual RS485 / RS422 - Converter Document code: MN67116_ENG Revision 1.000 Page 11 of 22 Industrial Electronic Devices RS422: For terminate the RS422 line with a 120Ω resistor it is necessary to put ON dip 1 for T line and/or put ON dip 2 for R line, like in figure. The maximum length of the cable should be 1200m (4000 feet). -
Page 12: Use Of Compositor Sw67116
User Manual RS485 / RS422 - Converter Document code: MN67116_ENG Revision 1.000 Page 12 of 22 Industrial Electronic Devices USE OF COMPOSITOR SW67116: To configure the Converter, use the available software that runs with Windows called SW67116. It is downloadable from the site www.adfweb.com and its operation is described in this document (this manual is referenced to the last version of the software present on our web site). -
Page 13: New Project / Open Project
User Manual RS485 / RS422 - Converter Document code: MN67116_ENG Revision 1.000 Page 13 of 22 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a Programmable “RS485 / RS422 - Converter”... -
Page 14: Software Options
User Manual RS485 / RS422 - Converter Document code: MN67116_ENG Revision 1.000 Page 14 of 22 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. - Page 15 User Manual RS485 / RS422 - Converter Document code: MN67116_ENG Revision 1.000 Page 15 of 22 Industrial Electronic Devices In the section “Software Settings”, it is possible to enable/disable some keyboard’s commands for an easier navigation inside the tables contained in the different sections of the software.
-
Page 16: Set Communication
User Manual RS485 / RS422 - Converter Document code: MN67116_ENG Revision 1.000 Page 16 of 22 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, RS485 and RS422. By Pressing the “Set Communication” button from the main window for SW67116 (Fig. 2) the window “Set Communication”... -
Page 17: Update Device
User Manual RS485 / RS422 - Converter Document code: MN67116_ENG Revision 1.000 Page 17 of 22 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. - Page 18 User Manual RS485 / RS422 - Converter Document code: MN67116_ENG Revision 1.000 Page 18 of 22 Industrial Electronic Devices Note: When you install a new version of the software, if it is the first time it is better you do the update of the Firmware in the HD67116 device.
-
Page 19: Mechanical Dimensions
User Manual RS485 / RS422 - Converter Document code: MN67116_ENG Revision 1.000 Page 19 of 22 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 6: Mechanical dimensions scheme for HD67116-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 20: Order Code
User Manual RS485 / RS422 - Converter Document code: MN67116_ENG Revision 1.000 Page 20 of 22 Industrial Electronic Devices ORDERING INFORMATIONS: The ordering part number is formed by a valid combination of the following: HD67116 – A 1 Connectors Type 1: Removable 5mm Screw Terminal Enclosure Type A: 1M, 35mm DIN Rail mounting... -
Page 21: Disclaimer
User Manual RS485 / RS422 - Converter Document code: MN67116_ENG Revision 1.000 Page 21 of 22 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 22: Warranties And Technical Support
User Manual RS485 / RS422 - Converter Document code: MN67116_ENG Revision 1.000 Page 22 of 22 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
