Industrial Electronic Devices
User Manual
Revision 1.100
English
Modbus Slave / Modbus Slave - Converter
(Order Code: HD67147-A1)
For Website information:
www.adfweb.com/?Product=HD67147
For Price information:
www.adfweb.com/?Price=HD67147-A1
Benefits and Main Features:
Modbus up to 115200bps
Industrial temperature range: -40°C / +85°C (-40°F / +185°F)
User Manual
ADFweb.com Srl – IT31010 – Mareno – Treviso
User Manual Modbus Slave / Modbus Slave
Document code: MN67147_ENG
For others Modbus devices, see also the following links:
Modbus Slave from/to ...
www.adfweb.com?Product=HD67002
www.adfweb.com?Product=HD67012
www.adfweb.com?Product=HD67029
www.adfweb.com?Product=HD67138
www.adfweb.com?Product=HD67151
www.adfweb.com?Product=HD67212
www.adfweb.com?Product=HD67222
www.adfweb.com?Product=HD67510
www.adfweb.com?Product=HD67516
www.adfweb.com?Product=HD67517
www.adfweb.com?Product=HD67580
www.adfweb.com?Product=HD67592
www.adfweb.com?Product=HD67616
www.adfweb.com?Product=HD67672
www.adfweb.com?Product=HD67712
www.adfweb.com?Product=HD67734
www.adfweb.com?Product=HD67765
www.adfweb.com?Product=HD67813
www.adfweb.com?Product=HD67843
www.adfweb.com?Product=HD67861
www.adfweb.com?Product=HD67934
www.adfweb.com?Product=HD67962
www.adfweb.com?Product=HD67C52
www.adfweb.com?Product=HD67D02
www.adfweb.com?Product=HD67E02
www.adfweb.com?Product=HD67E52
www.adfweb.com?Product=HD67F02
INFO:
www.adfweb.com
Revision 1.100
Page 1 of 23
(CANopen)
(CAN)
(M-Bus)
(DeviceNet Slave)
(DeviceNet Master)
(J1939)
(NMEA 2000)
(Modbus TCP Master)
(Modbus TCP Master)
(DMX)
(PROFIBUS Master)
(EtherNet/IP)
(NMEA0183)
(BACnet IP Slave)
(BACnet IP Master)
(IEC 61850 Server)
(IEC 61850 Client)
(KNX)
(DALI)
(IO-Link Master)
(MQTT)
(IO-Link Slave)
(EnOcean)
(LoRaWAN)
(EtherCAT Slave)
(EtherCAT Master)
(LoRaWAN Gateway)
Phone +39.0438.30.91.31
Advertisement
Related Manuals for ADF Web HD67147-A1
Summary of Contents for ADF Web HD67147-A1
- Page 1 Page 1 of 23 Industrial Electronic Devices User Manual Revision 1.100 English Modbus Slave / Modbus Slave - Converter (Order Code: HD67147-A1) For Website information: www.adfweb.com/?Product=HD67147 For others Modbus devices, see also the following links: Modbus Slave from/to … For Price information: www.adfweb.com/?Price=HD67147-A1...
-
Page 2: Table Of Contents
User Manual Modbus Slave / Modbus Slave Document code: MN67147_ENG Revision 1.100 Page 2 of 23 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that Page you need to check that the following document is: INDEX UPDATED DOCUMENTATION Updated;... -
Page 3: Security Alert
User Manual Modbus Slave / Modbus Slave Document code: MN67147_ENG Revision 1.100 Page 3 of 23 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device are required for each individual application, legal and safety regulation. -
Page 4: Example Of Connection
User Manual Modbus Slave / Modbus Slave Document code: MN67147_ENG Revision 1.100 Page 4 of 23 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 5: Connection Scheme
User Manual Modbus Slave / Modbus Slave Document code: MN67147_ENG Revision 1.100 Page 5 of 23 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme for HD67147-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 6: Characteristics
User Manual Modbus Slave / Modbus Slave Document code: MN67147_ENG Revision 1.100 Page 6 of 23 Industrial Electronic Devices CHARACTERISTICS: The configurable “Modbus Slave / Modbus Slave - Converter” allows the following characteristics: Galvanic isolation between the two Modbus ports. Mountable on 35mm Rail DIN;... -
Page 7: Power Supply
The devices can be powered at 8…24V AC and 12…35V DC. The consumption depends to the code of the device. For more details see the two tables below. Vmin Vmax Vmin Vmax HD67147-A1 Consumption at 24V DC: Device W/VA HD67147-A1 Caution: Not reverse the polarity power HD67147-A1 ADFweb.com Srl –... -
Page 8: Function Modes
User Manual Modbus Slave / Modbus Slave Document code: MN67147_ENG Revision 1.100 Page 8 of 23 Industrial Electronic Devices FUNCTION MODES: The device has got two functions mode depending of the position of the Dip1 of ‘Dip-Switch A’: The first, with Dip1 in Off position (factory setting), is used for the normal working of the device. The second, with Dip1 in On position, is used for upload the Project/Firmware. -
Page 9: Leds
User Manual Modbus Slave / Modbus Slave Document code: MN67147_ENG Revision 1.100 Page 9 of 23 Industrial Electronic Devices LEDS: The device has got four LEDs that are used to give information of the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode Blinks quickly: Boot state... -
Page 10: Ethernet
ETHERNET: The Ethernet connection must be made using Connector5 of HD67147-A1 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. To connect the device to an Hub/Switch is recommended the use of a straight cable, to connect the device to a PC/PLC/other is recommended the use of a cross cable. -
Page 11: Rs485
User Manual Modbus Slave / Modbus Slave Document code: MN67147_ENG Revision 1.100 Page 11 of 23 Industrial Electronic Devices RS485: To terminate the RS485 line with a 120Ω resistor it is necessary to put ON dip 1, like in figure. The maximum length of the cable should be 1200m (4000 feet). -
Page 12: Use Of Configurator Sw67147
User Manual Modbus Slave / Modbus Slave Document code: MN67147_ENG Revision 1.100 Page 12 of 23 Industrial Electronic Devices USE OF COMPOSITOR SW67147: To configure the Converter, use the available software that runs with Windows called SW67147. It is downloadable on the site www.adfweb.com and its operation is described in this document. -
Page 13: New Configuration / Open Configuration
User Manual Modbus Slave / Modbus Slave Document code: MN67147_ENG Revision 1.100 Page 13 of 23 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a Programmable “Modbus Slave / Modbus Slave - Converter”... -
Page 14: Software Options
User Manual Modbus Slave / Modbus Slave Document code: MN67147_ENG Revision 1.100 Page 14 of 23 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. - Page 15 User Manual Modbus Slave / Modbus Slave Document code: MN67147_ENG Revision 1.100 Page 15 of 23 Industrial Electronic Devices In the section “Software Settings”, it is possible to enable/disable some keyboard’s commands for an easier navigation inside the tables contained in the different sections of the software.
-
Page 16: Set Communication
User Manual Modbus Slave / Modbus Slave Document code: MN67147_ENG Revision 1.100 Page 16 of 23 Industrial Electronic Devices SET COMMUNICATION: This section defines the fundamental communication parameter of two ports Modbus. By pressing the “Set Communication” button from the main window for SW67147 (Fig. 2) the window “Set Communication”... - Page 17 User Manual Modbus Slave / Modbus Slave Document code: MN67147_ENG Revision 1.100 Page 17 of 23 Industrial Electronic Devices The means of the fields for the “Ethernet” section are: In the fields “IP Address” the IP address of Ethernet side of the converter is defined; In the fields “Subnet Mask”...
-
Page 18: Update Device
User Manual Modbus Slave / Modbus Slave Document code: MN67147_ENG Revision 1.100 Page 18 of 23 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. This by using the Ethernet port. - Page 19 User Manual Modbus Slave / Modbus Slave Document code: MN67147_ENG Revision 1.100 Page 19 of 23 Industrial Electronic Devices Note: When you receive the device, for the first time, you also have to update the Firmware in the HD67147 device. Warning: If Fig.
-
Page 20: Mechanical Dimensions
User Manual Modbus Slave / Modbus Slave Document code: MN67147_ENG Revision 1.100 Page 20 of 23 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 6: Mechanical dimensions scheme for HD67147-A1 ADFweb.com Srl – IT31010 – Mareno – Treviso INFO: www.adfweb.com Phone +39.0438.30.91.31... -
Page 21: Ordering Informations
Enclosure Type A: 1M, 35mm DIN Rail mounting Device Family HD67147: Modbus Slave / Modbus Slave - Converter Order Code: HD67147-A1 Modbus Slave / Modbus Slave - Converter ACCESSORIES: Order Code: AC34107 Null Modem Cable Fem/Fem DSub 9 Pin 1,5 m... -
Page 22: Disclaimer
User Manual Modbus Slave / Modbus Slave Document code: MN67147_ENG Revision 1.100 Page 22 of 23 Industrial Electronic Devices DISCLAIMER All technical content within this document can be modified without notice. The content of the document content is a recurring audit. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 23: Warranties And Technical Support
User Manual Modbus Slave / Modbus Slave Document code: MN67147_ENG Revision 1.100 Page 23 of 23 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
