ADF Web HD67166-A1 User Manual

Modbus tcp master / snmp - converter
Hide thumbs

Advertisement

Quick Links

Download this manual
Industrial Electronic Devices
User Manual
Revision 1.201
English
Modbus TCP Master / SNMP - Converter
(Order Code: HD67166-A1)
For Website information:
www.adfweb.com?Product=HD67166
For Price information:
www.adfweb.com?Price=HD67166-A1
Benefits and Main Features:
Electrical isolation
Temperature range: -40°C/+85°C (-40°F/+185°F)
User Manual
ADFweb.com S.r.l.
User Manual Modbus TCP Master / SNMP Agent
Document code: MN67166_ENG
For others SNMP Agents products, see also the following links:
Converter SNMP to
www.adfweb.com?Product=HD67040
www.adfweb.com?Product=HD67092
www.adfweb.com?Product=HD67155
www.adfweb.com?Product=HD67156
www.adfweb.com?Product=HD67158
www.adfweb.com?Product=HD67159
www.adfweb.com?Product=HD67160
www.adfweb.com?Product=HD67161
www.adfweb.com?Product=HD67162
www.adfweb.com?Product=HD67163
www.adfweb.com?Product=HD67164
www.adfweb.com?Product=HD67165
www.adfweb.com?Product=HD67167
www.adfweb.com?Product=HD67168
www.adfweb.com?Product=HD67169
www.adfweb.com?Product=HD67613
www.adfweb.com?Product=HD67626
www.adfweb.com?Product=HD67693
www.adfweb.com?Product=HD67726
www.adfweb.com?Product=HD67754
www.adfweb.com?Product=HD67779
www.adfweb.com?Product=HD67820
www.adfweb.com?Product=HD67850
www.adfweb.com?Product=HD67878
www.adfweb.com?Product=HD67954
www.adfweb.com?Product=HD67987
www.adfweb.com?Product=HD67B23
www.adfweb.com?Product=HD67B48
www.adfweb.com?Product=HD67B77
www.adfweb.com?Product=HD67C79
www.adfweb.com?Product=HD67D41
www.adfweb.com?Product=HD67E25
www.adfweb.com?Product=HD67E75
www.adfweb.com?Product=HD67F41
Do you have an your customer protocol?
www.adfweb.com?Product=HD67003
Do you need to choose a device? do you want help?
www.adfweb.com?Cmd=helpme
Revision 1.201
Page 1 of 33
(DMX)
(M-Bus Wireless)
(CAN)
(CANopen)
(EtherNet/IP Master)
(EtherNet/IP Slave)
(DeviceNet Master)
(DeviceNet Slave)
(J1939)
(M-Bus Master)
(Modbus Master)
(Modbus Slave)
(Modbus TCP Slave)
(PROFIBUS Master)
(PROFIBUS Slave)
(PROFINET Slave)
(S7comm)
(BACnet Slave)
(BACnet Master)
(IEC 61850 Server)
(IEC 61850 Client)
(KNX)
(DALI)
(IO-Link Master)
(MQTT)
(IO-Link Slave)
(OPC UA Client)
(OPC UA Server)
(PROFINET Master)
(EnOcean)
(LoRaWAN)
(EtherCAT Slave)
(EtherCAT Master)
(LoRaWAN Gateway)

Advertisement

loading
Need help?

Need help?

Do you have a question about the HD67166-A1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ADF Web HD67166-A1

Summary of Contents for ADF Web HD67166-A1

  • Page 1 English www.adfweb.com?Product=HD67040 (DMX) www.adfweb.com?Product=HD67092 (M-Bus Wireless) www.adfweb.com?Product=HD67155 (CAN) www.adfweb.com?Product=HD67156 (CANopen) Modbus TCP Master / SNMP - Converter www.adfweb.com?Product=HD67158 (EtherNet/IP Master) (Order Code: HD67166-A1) www.adfweb.com?Product=HD67159 (EtherNet/IP Slave) www.adfweb.com?Product=HD67160 (DeviceNet Master) www.adfweb.com?Product=HD67161 (DeviceNet Slave) For Website information: www.adfweb.com?Product=HD67162 (J1939) www.adfweb.com?Product=HD67166 www.adfweb.com?Product=HD67163 (M-Bus Master) www.adfweb.com?Product=HD67164...

  • Page 2: Updated Documentation

    User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 2 of 33 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that Page you need to check that the following document is: INDEX UPDATED DOCUMENTATION Updated...

  • Page 3: Security Alert

    User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 3 of 33 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application.

  • Page 4: Examples Of Connection

    User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 4 of 33 Industrial Electronic Devices EXAMPLES OF CONNECTION: ADFweb.com S.r.l.

  • Page 5: Connection Scheme

    User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 5 of 33 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme for HD67166-A1 ADFweb.com S.r.l.
  • Page 6 Page 6 of 33 Industrial Electronic Devices CHARACTERISTICS: The HD67166-A1 is a Modbus TCP Master / SNMP Agent Converter. It has the following characteristics: Up to 1024 bytes in reading and 1024 bytes in writing; Isolation between Power Supply - Ethernet.

  • Page 7: Power Supply

    The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below. Vmin Vmax Vmin Vmax Consumption at 24V DC: Device Consumption [W/VA] HD67166-A1 Caution: Do not reverse the polarity power HD67166-A1 ADFweb.com S.r.l.

  • Page 8: Function Modes

    User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 8 of 33 Industrial Electronic Devices FUNCTION MODES: The device has got two function modes depending on the position of the ‘Dip1 of Dip-Switch A’: The first, with ‘Dip1 of Dip-Switch A’ at “OFF” position, is used for the normal working of the device. The second, with ‘Dip1 of Dip-Switch A’...
  • Page 9 User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 9 of 33 Industrial Electronic Devices LEDS: The device has got six LEDs that are used to give information about the functioning status. The various meanings of the LEDs are described in the table below. Normal Mode Boot Mode ON: Device powered...
  • Page 10 User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 10 of 33 Industrial Electronic Devices ETHERNET: The SNMP connection, Modbus TCP connection and the updating of the converters must be made using Connector3 and/or Connector4 with at least a Category 5E cable.
  • Page 11 User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 11 of 33 Industrial Electronic Devices USE OF COMPOSITOR SW67166: To configure the Converter, use the available software that runs with Windows called SW67166. It is downloadable on the site www.adfweb.com and its operation is described in this document.

  • Page 12: New Configuration / Open Configuration

    User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 12 of 33 Industrial Electronic Devices NEW CONFIGURATION / OPEN CONFIGURATION: “New Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a programmable “Modbus TCP Master / SNMP Agent - Converter”...

  • Page 13: Software Options

    User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 13 of 33 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor.

  • Page 14: Set Communication

    User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 14 of 33 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, SNMP and Modbus TCP. By Pressing the “Set Communication”...

  • Page 15: Set Access

    User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 15 of 33 Industrial Electronic Devices SET ACCESS: By pressing the “Set Access” button from the main window for SW67166 (Fig. 2) the window “Set Modbus Access” appears. This window is divided in two parts, the "Modbus Read"...
  • Page 16 User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 16 of 33 Industrial Electronic Devices In the field “Start Bit” the starting bit of the first byte of the field “Position” is defined. Valid only for the “Coil Status” and “Input Status”;...
  • Page 17 User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 17 of 33 Industrial Electronic Devices If the field “Swap” is checked, the data written the Modbus registers are swapped; If the field “Swap Word” is checked, the words of the data written are swapped between them; If the field “Force FC16”...
  • Page 18 User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 18 of 33 Industrial Electronic Devices SET SNMP ACCESS (only if “Dynamic Map” is used): By pressing the “Set SNMP Access” button from the main window for SW67166 (Fig. 2) the “Set SNMP Access” window appears (Fig. 5). In this section, it is possible to create the OIDs for SNMP side to read or write using GET and SET commands or to be sent as TRAP messages.
  • Page 19 User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 19 of 33 Industrial Electronic Devices The data of the columns in the “SNMP Write” have the following meanings: field “Enable” checked, the SNMP OID is enabled;...

  • Page 20: Update Device

    User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 20 of 33 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary.
  • Page 21 User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 21 of 33 Industrial Electronic Devices Note: When you install a new version of the software, if it is the first time it is better you do the update of the Firmware in the HD67166 device.
  • Page 22 User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 22 of 33 Industrial Electronic Devices SNMP COMMUNICATION (Dynamic Map) In order to read/write the data from/to Modbus TCP side, it is necessary to use specific SNMP commands in order to see the SNMP Input and write the SNMP Output.
  • Page 23 User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 23 of 33 Industrial Electronic Devices Each SNMP variable created will have its own OID and it will be created following this rule: OID 1 (first row of “Set SNMP Access -> SNMP Read” table): .1.3.6.1.4.1.49314.1.1.1.4.9.1 OID 2 (second row of “Set SNMP Access ->...
  • Page 24 User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 24 of 33 Industrial Electronic Devices Writing Modbus TCP data from SNMP: In order to write the data from the HD67166, it is necessary to use the SET command. Each OID defined in the section “Set SNMP Access ->...
  • Page 25 User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 25 of 33 Industrial Electronic Devices Each SNMP variable created will have its own OID and it will be created following this rule: OID 1 (first row of “Set SNMP Access -> SNMP Write” table): .1.3.6.1.4.1.49314.1.1.1.5.9.1 OID 2 (second row of “Set SNMP Access ->...
  • Page 26 User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 26 of 33 Industrial Electronic Devices TRAP messages from SNMP: All the OIDs defined in the “Set SNMP Access -> SNMP Read” table can be sent as TRAP messages too. The TRAP messages are contained in the MIB tree and they have these OIDs: TRAP 1 (first row of “Set SNMP Access ->...
  • Page 27 User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 27 of 33 Industrial Electronic Devices SNMP COMMUNICATION (Fixed Map) In order to read/write the data from/to Modbus side, it is necessary to use specific SNMP commands in order to see the SNMP Input and write the SNMP Output.
  • Page 28 User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 28 of 33 Industrial Electronic Devices Writing Modbus TCP data from SNMP: In order to write the data to the HD67166 it is necessary to use the “snmpset” command. The Output array is contained to this internal directory: 1.3.6.1.4.1.33118.1.1.1.4.x.0, where ‘x’...
  • Page 29 User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 29 of 33 Industrial Electronic Devices Note: The data blocks from 1 to 8 are used to read/write the entire internal SNMP arrays of the converter. The data are represented in bytes.

  • Page 30: Mechanical Dimensions

    User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 30 of 33 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 9: Mechanical dimensions scheme for HD67166-A1 ADFweb.com S.r.l.

  • Page 31: Ordering Informations

    Enclosure Type A: 1M, 35mm DIN Rail mounting Device Family HD67166: Modbus TCP Master / SNMP Agent - Converter Order Code: HD67166-A1 Modbus TCP Master / SNMP Agent – Converter ACCESSORIES: Order Code: AC34011 35mm Rail DIN - Power Supply 220/240V AC 50/60Hz – 12 V DC Order Code: AC34012 35mm Rail DIN - Power Supply 220/240V AC 50/60Hz –...
  • Page 32 User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 32 of 33 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user.

  • Page 33: Warranties And Technical Support

    User Manual Modbus TCP Master / SNMP Agent Document code: MN67166_ENG Revision 1.201 Page 33 of 33 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following:...
