ADP5055-EVALZ
Enabling the Dynamic Voltage Scaling (DVS)
The ADP5055 provides a DVS function for Channel 1 to
Channel 3. These reference voltages can be programmed in real
time via the PMBus serial interface in Register 0xDC (DVS_LIM1)
to Register 0xDE (DVS_LIM3). The DVS_INTVALx bits in
Register 0xDB (DVS_CFG) are used to set the step interval during
the transition for individual channels.
Figure 17 shows a typical DVS voltage transition.
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
User Guide
1
CH1 500mV/DIV 1MΩ CH1 500mV/DIV 1MΩ
Figure 17. Channel 1 DVS from 0.62 V to 1.24 V, 12 mV/ms, V
Rev. 0 | Page 11 of 16
UG-1930
T
B B
500M 500M 10.0ms/DIV 1.0MS/s
W: W:
A CH1 1.07V
1.0µs/pt
= 12 V
IN
