Chapter 3: System Setup
8. Place the CPU into the processor carrier. The triangular mark on the CPU
should be aligned with the triangular mark on the processor carrier.
Triangular
Mark
Processor
Carrier
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
9. Install the processor carrier with the CPU assembled onto the heatsink.
Make sure that the triangular mark on the processor carrier aligns with
the number 1 marking on the label located at the top of the heatsink,
and apply thermal paste.
41
1
NSA 7160R User Manual
