Chapter 2: Jumpers and Connectors

XDP Debug Connector (For CPU1)

Connector type: 2x30 60-pin header
Connector location: CN8
60
2
1 59
Pin Definition
1 PD_CPU0_DBP_PIN1
2 NC
3 NC
4 NC
5 NC
6 NC
7 NC
8 PD_TRST_CPU0
9 NC
10 NC
11 NC
12 PVNN_TERM_CPU0
13 TRC_CPU0_PTI0_CLK0
14 TRC_CPU0_PTI1_CLK0
15 GND
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
16 GND
17 GND
18 TRC_CPU0_PTI10
19 TRC_CPU0_PTI00
20 TRC_CPU0_PTI11
21 TRC_CPU0_PTI01
22 TRC_CPU0_PTI12
23 TRC_CPU0_PTI02
24 TRC_CPU0_PTI13
25 TRC_CPU0_PTI03
26 TRC_CPU0_PTI14
27 TRC_CPU0_PTI04
28 TRC_CPU0_PTI15
29 TRC_CPU0_PTI05
30 TRC_CPU0_PTI16
Pin Definition
31 TRC_CPU0_PTI06
32 TRC_CPU0_PTI17
33 TRC_CPU0_PTI07
34 NC
35 TRC_CPU0_PTI08
36 NC
37 TRC_CPU0_PTI09
38 TRC_CPU0_PTI18
39 TRC_CPU0_PTI010
40 TRC_CPU0_PTI19
41 TRC_CPU0_PTI011
42 PWRGD_CPU0_LVC1_MIPI60
43 TRC_CPU0_PTI012
44 TRC_CPU0_PTI110
45 TRC_CPU0_PTI013
17
Pin Definition
46 TRC_CPU0_PTI111
47 TRC_CPU0_PTI014
48 TRC_CPU0_PTI112
49 TRC_CPU0_PTI015
50 TRC_CPU0_PTI113
51 NC
52 P3V3_AUX
DBP_CPU0_HOOK9_MBP3_
53
QS_R1_N
54 TRC_CPU0_PTI114
DBP_CPU0_HOOK8_MBP2_
55
QS_R1_N
56 TRC_CPU0_PTI115
57 GND
58 GND
59 TRC_CPU0_PTI0_CLK1
60 TRC_CPU0_PTI1_CLK1
