Chapter 2: Jumpers and Connectors
Header to LED with Cable
Connector type: 2X1 2-Pin
Connector location: JP18
1
2
Pin
Definition
1
P3V3_CPLD
2
ID_LED_N
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
SATA Connector
Connector type: 1X7 7-Pin
Connector location: SATA1, SATA2
7
1
Pin
Definition
1
GND
4
GND
7
GND
34
Pin
Definition
2
TXP
3
TXN
5
RXN
6
RXP
NSA 7160R User Manual
