Chapter 2: Jumpers and Connectors

XDP Debug Connector (For PCH)

Connector type: 2x30 60-pin header
Connector location: CN7
60
2
1 59
Pin Definition
1 P1V05_PCH_AUX
2 JTAG_DBP_TMS_R
3 JTAG_DBP_CPU_TCK_R
4 JTAG_DBP_TDO_R
5 JTAG_DBP_TDI_R
6 RST_DBP_RST_CO_N
7 DBP_PMODE
8 PD_TRST_PD3
9 NC
10 H_DBP_PREQ_N_R
11 H_DBP_PRDY_R_N
12 P1V8_PCH_AUX
13 TRC_PCH_PTI0_CLK
14 GND
DBP_PCH_DEBUG_
15
CONSENT_N
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
16 GND
17 FM_DBP_PRESENT_R_N
18 NC
19 TRC_PCH_PTI0
20 NC
21 TRC_PCH_PTI1
22 NC
23 TRC_PCH_PTI2
24 NC
25 TRC_PCH_PTI3
26 NC
27 TRC_PCH_PTI4
28 NC
29 TRC_PCH_PTI 5
30 NC
Pin Definition
31 TRC_PCH_PTI 6
32 NC
33 TRC_PCH_PTI 7
34 NC
35 TRC_PCH_PTI 8
36 DBP_BOOT_HALT_N
37 TRC_PCH_PTI 9
38 FM_CPU_FBRK_DEBUG_N
39 TRC_PCH_PTI10
40 DBP_POWER_BTN_N
41 TRC_PCH_PTI11
42 RST_DBP_RSMRST_N
43 TRC_PCH_PTI12
44 NC
45 TRC_PCH_PTI13
16
Pin Definition
46 NC
47 TRC_PCH_PTI14
SMB_HOST_STBY_LVC3_
48
XDP_SCL
49 TRC_PCH_PTI15
SMB_HOST_STBY_LVC3_
50
XDP_SDA
51 JTAG_DBP_PCH_R_TCK
52 P3V3_AUX
53 DBP_CPU_HOOK9_MBP3_N
54 NC
55 DBP_CPU_HOOK8_MBP2_N
56 NC
57 GND
58 GND
59 TRC_PCH_PTI1_CLK
60 GND
