Chapter 2: Jumpers and Connectors

MCIO Connector

Connector type: 2X37 74-Pin
Connector location: CN10, CN13, CN16, CN18
B1 B37
A1 A37
Pin Definition
A1 GND
A2 PE_SLOT_RX_DP0
A3 PE_SLOT_RX_DN0
A4 GND
A5 PE_SLOT_RX_DP1
A6 PE_SLOT_RX_DN1
A7 GND
A8 NC
A9 NC
A10 GND
A11 NC
A12 NC
A13 GND
A14 PE_SLOT_RX_DP2
A15 PE_SLOT_RX_DN2
A16 GND
A17 PE_SLOT_RX_DP3
A18 PE_SLOT_RX_DN3
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
B1 GND
B2 PE_SLOT_TX_C_DP0
B3 PE_SLOT_TX_C_DN0
B4 GND
B5 PE_SLOT_TX_C_DP1
B6 PE_SLOT_TX_C_DN1
B7 GND
B8 NC
B9 NC
B10 GND
B11 NC
B12 NC
B13 GND
B14 PE_SLOT_TX_C_DP2
B15 PE_SLOT_TX_C_DN2
B16 GND
B17 PE_SLOT_TX_C_DP3
B18 PE_SLOT_TX_C_DN3
Pin Definition
A19 GND
A20 PE_SLOT_RX_DP4
A21 PE_SLOT_RX_DN4
A22 GND
A23 PE_SLOT_RX_DP5
A24 PE_SLOT_RX_DN5
A25 GND
A26 NC
A27 NC
A28 GND
A29 NC
A30 NC
A31 GND
A32 PE_SLOT_RX_DP6
A33 PE_SLOT_RX_DN6
A34 GND
A35 PE_SLOT_RX_DP7
A36 PE_SLOT_RX_DN7
A37 GND
21
Pin Definition
B19 GND
B20 PE_SLOT_TX_C_DP4
B21 PE_SLOT_TX_C_DN4
B22 GND
B23 PE_SLOT_TX_C_DP5
B24 PE_SLOT_TX_C_DN5
B25 GND
B26 NC
B27 NC
B28 GND
B29 NC
B30 NC
B31 GND
B32 PE_SLOT_TX_C_DP6
B33 PE_SLOT_TX_C_DN6
B34 GND
B35 PE_SLOT_TX_C_DP7
B36 PE_SLOT_TX_C_DN7
B37 GND
