Chapter 2: Jumpers and Connectors
Pin Definition
A16 GND
A17 PE_SLOT_RX_DN0
A18 PE_SLOT_RX_DP0
A19 GND
A20 PE_SLOT_RX_DN1
A21 PE_SLOT_RX_DP1
A22 GND
A23 PE_SLOT_RX_DN2
A24 PE_SLOT_RX_DP2
A25 GND
A26 PE_SLOT_RX_DN3
A27 PE_SLOT_RX_DP3
A28 GND
A29 GND
A30 PE_SLOT_RX_DN4
A31 PE_SLOT_RX_DP4
A32 GND
A33 PE_SLOT_RX_DN5
A34 PE_SLOT_RX_DP5
A35 GND
A36 PE_SLOT_RX_DN6
A37 PE_SLOT_RX_DP6
A38 GND
A39 PE_SLOT_RX_DN7
A40 PE_SLOT_RX_DP7
A41 GND
A42 NO USE
A43 GND
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
B16 GND
B17 PE_SLOT_TX_C_DN0
B18 PE_SLOT_TX_C_DP0
B19 GND
B20 PE_SLOT_TX_C_DN1
B21 PE_SLOT_TX_C_DP1
B22 GND
B23 PE_SLOT_TX_C_DN2
B24 PE_SLOT_TX_C_DP2
B25 GND
B26 PE_SLOT_TX_C_DN3
B27 PE_SLOT_TX_C_DP3
B28 GND
B29 GND
B30 PE_SLOT_TX_C_DN4
B31 PE_SLOT_TX_C_DP4
B32 GND
B33 PE_SLOT_TX_C_DN5
B34 PE_SLOT_TX_C_DP5
B35 GND
B36 PE_SLOT_TX_C_DN6
B37 PE_SLOT_TX_C_DP6
B38 GND
B39 PE_SLOT_TX_C_DN7
B40 PE_SLOT_TX_C_DP7
B41 GND
B42 NO USE
B43 GND
Pin Definition
A44 PE_SLOT_RX_DN8
A45 PE_SLOT_RX_DP8
A46 GND
A47 PE_SLOT_RX_DN9
A48 PE_SLOT_RX_DP9
A49 GND
A50 PE_SLOT_RX_DN10
A51 PE_SLOT_RX_DP10
A52 GND
A53 PE_SLOT_RX_DN11
A54 PE_SLOT_RX_DP11
A55 GND
A56 PE_SLOT_RX_DN12
A57 PE_SLOT_RX_DP12
A58 GND
A59 PE_SLOT_RX_DN13
A60 PE_SLOT_RX_DP13
A61 GND
A62 PE_SLOT_RX_DN14
A63 PE_SLOT_RX_DP14
A64 GND
A65 PE_SLOT_RX_DN15
A66 PE_SLOT_RX_DP15
A67 GND
A68
A69
A70 NO USE
20
Pin Definition
B44 PE_SLOT_TX_C_DN8
B45 PE_SLOT_TX_C_DP8
B46 GND
B47 PE_SLOT_TX_C_DN9
B48 PE_SLOT_TX_C_DP9
B49 GND
B50 PE_SLOT_TX_C_DN10
B51 PE_SLOT_TX_C_DP10
B52 GND
B53 PE_SLOT_TX_C_DN11
B54 PE_SLOT_TX_C_DP11
B55 GND
B56 PE_SLOT_TX_C_DN12
B57 PE_SLOT_TX_C_DP12
B58 GND
B59 PE_SLOT_TX_C_DN13
B60 PE_SLOT_TX_C_DP13
B61 GND
B62 PE_SLOT_TX_C_DN14
B63 PE_SLOT_TX_C_DP14
B64 GND
B65 PE_SLOT_TX_C_DN15
B66 PE_SLOT_TX_C_DP15
B67 GND
B68
B69
B70 NO USE
