Chapter 2: Jumpers and Connectors

VGA Connector

Connector type: 1x16 16-pin header
Connector location: J3
1 16
Pin Definition
1 VGA_VCC
2 GND
3 NC
4 SMB_BMC_DDC_SCL_R1
SMB_BMC_DDC_SDA_
5
R1
6 NC
V_BMC_GFX_REAR_
7
VSYN_R3
8 GND
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
V_BMC_GFX_REAR_
9
HSYN_R3
10 NC
11 GND
V_BMC_GFX_REAR_
12
BLU_R1
13 GND
V_BMC_GFX_REAR_
14
GRN_R1
15 GND
V_BMC_GFX_REAR_
16
RED_R1

Fan Wafer Connector

Connector type: 1X9 9-Pin
Connector location: J10, J11, J12
1 9
Pin Definition
1 P12V
2 P12V
3 TACH FRONT
4 TACH REAR
5 N/C
6 PWM REAR
7 PWM FRONT
8 GND
9 GND
32
