Chapter 2: Jumpers and Connectors
Pin
Definition
A12
PE_SLOT3_PRSNTB2#
A13
GND
A14
PE_SLOT3_CLK1_DN
A15
PE_SLOT3_CLK1_DP
A16
GND
A17
PE_SLOT3_RX_DP15
A18
PE_SLOT3_RX_DN15
A19
GND
A20
PE_SLOT3_RX_DP14
A21
PE_SLOT3_RX_DN14
A22
GND
A23
PE_SLOT3_RX_DP13
A24
PE_SLOT3_RX_DN13
A25
GND
A26
PE_SLOT3_RX_DP12
A27
PE_SLOT3_RX_DN12
A28
GND
A29
GND
A30
PE_SLOT3_RX_DP11
A31
PE_SLOT3_RX_DN11
A32
GND
A33
PE_SLOT3_RX_DP10
A34
PE_SLOT3_RX_DN10
A35
GND
A36
PE_SLOT3_RX_DP9
A37
PE_SLOT3_RX_DN9
A38
GND
A39
PE_SLOT3_RX_DP8
A40
PE_SLOT3_RX_DN8
A41
GND
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
B12
AUX_PWR_EN_SLOT
B13
GND
B14
PE_SLOT3_CLK0_DN
B15
PE_SLOT3_CLK0_DP
B16
GND
B17
PE_SLOT3_TX_DP15
B18
PE_SLOT3_TX_DN15
B19
GND
B20
PE_SLOT3_TX_DP14
B21
PE_SLOT3_TX_DN14
B22
GND
B23
PE_SLOT3_TX_DP13
B24
PE_SLOT3_TX_DN13
B25
GND
B26
PE_SLOT3_TX_DP12
B27
PE_SLOT3_TX_DN12
B28
GND
B29
GND
B30
PE_SLOT3_TX_DP11
B31
PE_SLOT3_TX_DN11
B32
GND
B33
PE_SLOT3_TX_DP10
B34
PE_SLOT3_TX_DN10
B35
GND
B36
PE_SLOT3_TX_DP9
B37
PE_SLOT3_TX_DN9
B38
GND
B39
PE_SLOT3_TX_DP8
B40
PE_SLOT3_TX_DN8
B41
GND
Pin
Definition
A42
PE_SLOT3_PRSNTB1#
A43
GND
A44
PE_SLOT3_RX_DP7
A45
PE_SLOT3_RX_DN7
A46
GND
A47
PE_SLOT3_RX_DP6
A48
PE_SLOT3_RX_DN6
A49
GND
A50
PE_SLOT3_RX_DP5
A51
PE_SLOT3_RX_DN5
A52
GND
A53
PE_SLOT3_RX_DP4
A54
PE_SLOT3_RX_DN4
A55
GND
A56
PE_SLOT3_RX_DP3
A57
PE_SLOT3_RX_DN3
A58
GND
A59
PE_SLOT3_RX_DP2
A60
PE_SLOT3_RX_DN2
A61
GND
A62
PE_SLOT3_RX_DP1
A63
PE_SLOT3_RX_DN1
A64
GND
A65
PE_SLOT3_RX_DP0
A66
PE_SLOT3_RX_DN0
A67
GND
A68
NC
A69
NC
A70
PE_SLOT34_PWRBRK0#
23
Pin
Definition
B42
PE_SLOT3_PRSNTB0#
B43
GND
B44
PE_SLOT3_TX_DP7
B45
PE_SLOT3_TX_DN7
B46
GND
B47
PE_SLOT3_TX_DP6
B48
PE_SLOT3_TX_DN6
B49
GND
B50
PE_SLOT3_TX_DP5
B51
PE_SLOT3_TX_DN5
B52
GND
B53
PE_SLOT3_TX_DP4
B54
PE_SLOT3_TX_DN4
B55
GND
B56
PE_SLOT3_TX_DP3
B57
PE_SLOT3_TX_DN3
B58
GND
B59
PE_SLOT3_TX_DP2
B60
PE_SLOT3_TX_DN2
B61
GND
B62
PE_SLOT3_TX_DP1
B63
PE_SLOT3_TX_DN1
B64
GND
B65
PE_SLOT3_TX_DP0
B66
PE_SLOT3_TX_DN0
B67
GND
B68
NC
B69
NC
B70
PE_SLOT3_PRSNTB3#
