Chapter 2: Jumpers and Connectors
Pin
Definition
139
GND
141
FP_SYS_RESET_R1_N
143
RST_BTN_BMC_N
145
GND
147
PE_BMC_TXN
149
PE_BMC_TXP
151
GND
153
PCIE_RX_BMC_DN
155
PCIE_RX_BMC_DP
157
GND
CLK_100M_GEN3_BMC_
159
PE_DN
CLK_100M_GEN3_BMC_
161
PE_DP
163
GND
RST_LPC_LRST_ESPI_RST_
165
BMC_R_N
167
ESPI_IO1_LPC_LAD1_R
169
ESPI_IO0_LPC_LAD0_R
IRQ_LPC_SERIRQ_ESPI_
171
ALERT_N_BMC
173
ESPI_CS1_N_LFRAME_N_BMC
175
ESPI_IO3_LPC_LAD3_R
177
ESPI_IO2_LPC_LAD2_R
179
PCICLK_BMC
181
BMC_I2C9SCL_R
183
BMC_I2C9SDA_R
185
GND
187
PWRGD_PCH_PWROK_R2
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
H_CPU0_MEMHOT_OUT_
140
LVC1_BMC_N
142
RST_PLTRST_B_N
144
BMC_GPIO100
146
BMC_GPIO101
148
NC
150
NC
152
PGPPA_AUX
FM_CPU1_MEMHOT_OUT_
154
BMC_N
156
FM_BMC_ONCTL_N_PLD_R
158
BMC_GPIO106
160
DBP_PRESENT_IN_R2_N
162
BMCJTAG1TRST
164
JTAG_TDO_BMC
166
JTAG_TDI_BMC
168
BMC_JTAG1RTCK
170
JTAG_TCK_BMC
172
JTAG_TMS_BMC
174
A_P12V_SCALED
176
A_P3V3_SCALED
178
A_P5V_SCALED
180
A_P1V05_PCH_AUX_SCALED
182
A_PVNN_PCH_AUX_SCALED
184
A_VCC_CPU0_SCALED
186
A_VCC_CPU1_SCALED
PVCCFA_EHV_FIVRA_CPU0_
188
SCALED
Pin
Definition
FM_CPU0_SKTOCC_LVT3_
189
R1_N
191
GND
193
FM_CPU_ERR2_LVT3_BMC_N
195
AC_FAIL_PSU_BMC
197
GND
199
FP_BMC_PWR_BTN_R_N
201
PWR_BTN_BMC_N
203
GND
205
BMC_I2C03SCL
207
BMC_I2C03SDA
209
FP_ID_BTN_PFR_BMC_N
211
PWRGD_P2V5_BMC_AUX_R
213
FM_P1V0_BMC_AUX_EN_R
215
GND
217
USB2_P10_DN
219
USB2_P10_DP
221
GND
223
USB2_P12_BMC_DN
225
USB2_P12_BMC_DP
227
GND
229
NCSI_TXD0_B
231
NCSI_RXD0_B
233
GND
235
NCSI_RXD1_B
237
NCSI_TXD1_B
29
Pin
Definition
190
SPI_PFR_PCH_RNBMC_CS0_N
192
BMC_GPO1
194
BMC_GPO2
196
BMC_GPIO16
198
SPI_IBMC_SSB_CS0_N
SPI_BMC_MUXED_BIOS_
200
IO0_R
SPI_BMC_MUXED_BIOS_
202
IO1_R
SPI_BMC_MUXED_BIOS_
204
IO2_R
SPI_BMC_MUXED_BIOS_
206
IO3_R
SPI_BMC_MUXED_BIOS_
208
CLK_R
210
SPI_IBMC_SSB_CS1_N
212
GND
214
RMIIMDIO
216
NCSI_CRS_DV_A
218
RMIIMDC
220
NCSI_IBMC_CLK_A
222
BMC_RMIIRXER
224
NCSI_TX_EN_A
226
GND
228
NCSI_RXD0_A
230
NCSI_RXD1_A
232
GND
234
NCSI_TXD0_A
236
NCSI_TXD1_A
238
GND
NSA 7160R User Manual
