Communication Ports
4.2 SFP Transceivers
1
2
Figure 4.2
LEDs
Each port features an LED that indicates the link/activity state of the port.
Green (Solid)
Green (Blinking)
Off
Specifications
For specifications on the available fiber optic Ethernet ports, refer to "Fiber Optic
Ethernet Port Specifications" (Page 24).
4.2

SFP Transceivers

The RUGGEDCOM RSG908C supports up to four Small Form-Factor Pluggable (SFP)
transceiver sockets, which are compatible with a wide array of SFP transceivers
available from Siemens.
LEDs
Each socket features an LED that indicates its link state.
Green (Solid)
Green (Blinking)
Off
Compatible SFP Transceivers
For more information about which SFP transceivers are compatible with the
RUGGEDCOM RSG908C, as well as instructions for ordering and installation/
removal, refer to the
support.industry.siemens.com/cs/ca/en/view/109482309]".
Note
Only use SFP transceivers approved by Siemens for RUGGEDCOM products. Siemens
accepts no liability as a result of performance issues related in whole or in part to
third-party components.
22
Tx Connector
Rx Connector
LC Port
State
State
"RUGGEDCOM SFP Transceiver Catalog [https://
Description
Link established
Link activity
No link detected
Description
Link established
Activity
No link detected
