6.2 EMC and Environmental Type Tests
60255-27
EMC Immunity Type Tests per IEEE 1613
Note
RUGGEDCOM products meet Class 1 requirements for copper Ethernet
configurations and Class 2 for fiber Ethernet configurations. Class 1 allows for
temporary communication loss, while Class 2 requires error-free and interrupted
communications.
32
Test
IEC Dielectric Strength
HV Impulse
Test
IEEE 1613
IEEE 1613
IEEE 1613
IEEE 1613
IEEE 1613
IEEE 1613
IEEE 1613.1
IEC 61000-4-10
Description
Signal Ports
DC Power
Ports
AC Power
Ports
Signal Ports
DC Power
Ports
AC Power
Ports
Description
ESD Enclosure Contact
Enclosure Air
Radiated RFI Enclosure Ports
Fast Signal Ports
Transient
DC Power Ports
AC Power Ports
Earth Ground Ports
Oscillatory Signal Ports
DC Power Ports
HV Impulse Signal Ports
DC Power Ports
AC Power Ports
Dielectric Signal Ports
Strength
DC Power Ports
AC Power Ports
Damped Enclosure Ports
Oscillating
Magnetic
Field
Test Levels
100% for 0.05 s
2 kV (Failsafe Relay Output)
2 kV or 2.8kV DC
2 kV
5 kV (Failsafe Relay Output)
5 kV
5 kV
Test Levels
± 8 kV
± 15 kV
35 V/m
± 4 kV @ 2.5 kHz, 5 kHz
± 4 kV @ 2.5 kHz, 5 kHz
± 4 kV @ 2.5 kHz, 5 kHz
± 4 kV
2.5 kV Common
Mode @ 1 MHz
2.5 kV Common
Mode @ 1 MHz
1 kV Differential
Mode @ 1 MHz
5 kV (Failsafe Relay)
2 kV (Failsafe Relay)
2.8 kVDC or 2 kV
100 A/m for 1 s (100
kHz and 1 MHz)
