5.4 Supported Networking Standards
5.4

Supported Networking Standards

The following networking standards are supported by RUGGEDCOM RSG908C:
Standard
IEEE 802.3x
IEEE 802.3z
IEEE 802.3ab
IEEE 802.1D
IEEE 802.1Q
802.1Q-2005
IEEE 802.1w
IEEE 802.1p
IEEE 802.1x
IEEE 802.3
IEEE 802.3ad
IEEE 802.3u
1588-2008
62439-2:2016
5.5

Fiber Optic Ethernet Port Specifications

The following details the specifications for fiber Ethernet ports that can be ordered
with the RUGGEDCOM RSG908C.
Note
•
•
Data Mode Connector Cable
Rate
(Mbps)
100 MM LC
100 MM LC
a
Typical.
24
10 Mbps
Ports
•
•
•
IEEE •
•
•
•
•
•
IEEE •
IEC •
All optical power numbers are listed as dBm averages. To convert from average
to peak, add 3 dBm. To convert from peak to average, subtract 3 dBm.
Maximum segment length is greatly dependent on factors such as fiber quality,
and the number of patches and splices. Consult a Siemens sales associate when
determining maximum segment distances.
Wavelength
(μm) (nm)
Transmit Receive
50/125 1308
62.5/125 1308
100 Mbps 1000 Mbps Ports
Ports
•
•
•
•
•
•
•
•
•
•
•
Transmit
a
Power (dBm)
Min Max
1308 -22.5 -14
1308 -20 -14
Notes
• Full Duplex Operation
• 1000Base-LX
• 1000Base-Tx
• MAC Bridges
• VLAN (Virtual LAN)
• Multiple Spanning
Tree Protocol (MSTP)
• Rapid Spanning
Tree Protocol (RSTP)
• Priority Levels
• Port-based network
access control
10Base-T
• Link aggregation
100Base-TX/100Base-FX
• Precision Time Control
(PTP) Version 2
• Media Redundancy
Protocol (MRP)
Receiver Receiver Distance
Sensitivity Saturation
(dBm) (dBm)
-31 -14
-31 -14
Equipment Manual, 11/2023, C79000-G8976-1404-15
Power
a
(km) Budget
2 11
2 11
RUGGEDCOM RSG908C
