Introducing the IQS-1600 High Speed Power Meter
Main Features
IQS-1610
Analog
output
port
ANALOG OUT
EXT.
TRIG
LED push
button
It features a high sampling rate and fast stabilization, and comes in one-,
two- or four-channel options (each detector is independent). It also
provides you with power level and TTL voltage synchronization triggers.
The synchronization triggers will operate simultaneously on dual- and
quadruple-channel models.
The graphical display mode shows all channels on a real-time graph,
which you can analyze afterwards.
The IQS-1600 High Speed Power Meter supports local control (via the
IQS Manager software) and remote control (through GPIB, RS-232, or
Ethernet TCP/IP using SCPI commands or the provided LabVIEW drivers).
For more information, refer to the IQS platform user guide.
2
IQS-1620
ANALOG OUT
C1
C2
IQS-1600
Power Meter
IQS-1600
2-Ch Power Meter
External trigger port
(SMB connector)
IQS-1640
C1
C2
C3
C4
EXT.
TRIG
IQS-1600
4-Ch Power Meter
External connector (used only
with the IQS-12004B system)
Fiber-optic
adapter
Optical
detector port
External trigger
port (SMB
Sync
connector)
Out
Sync In
Trig
Retaining
screw knob
IQS-1600
