EXFO USER GUIDE User Manual page 146

SCPI Command Reference
Product-Specific Commands—Description
Description
Syntax
Parameter(s)
Response Syntax
Response(s)
Example(s)
See Also
138
:MEASure[1..n][:SCALar]:POWer:
This query returns the maximum power
measurement value recorded for a channel in
Continuous acquisition mode.
:MEASure[1..n][:SCALar]:POWer:MAXimum?
None
<MaxPower>
MaxPower:
The response data syntax for <MaxPower> is
defined as a <NR3 NUMERIC RESPONSE DATA>
element.
This query returns the power measurement
maximum for a channel in the currently selected
unit.
The number of digits after the decimal depends
on the selected resolution. To change the
resolution of the displayed power value in dB or
dBm, use the FORM[:DATA] command. To know
the current measurement unit, use the
SENS:POW[:DC]:UNIT? query.
INIT:EXTR ON
MEAS:POW:MAX?
INITiate:EXTRema
MEASure:SCALare:POWer:MIN?
MAXimum?
IQS-1600
