Integration into BACnet Systems

6.3. Integration into BACnet Systems
NOTICE
You can see the Protocol Implementation Conformance Statement (PICS) document on
www.intesis.com/docs/bacnet-client-pic-statement-770

6.3.1. BACnet Objects

NOTICE
This part is common for BACnet MS/TP and BACnet/IP.
Input object types:
• Binary input
Output object types:
• Binary output
• Multistate output
• Analog output
The following tables list all available BACnet objects for this gateway.
Table 8. Global signals
Object name
On/Off (all units)
Mode (all units)
FanSpeed (all units)
FanSpeed (all units)
Air louver Position (all units)
Temperature Setpoint (all units)
Table 9. Oudoor units signals
Object name
OUXX_Outdoor Air Temp.
OUXX_Comp.Top Temp.
USER MANUAL Version 1.0.6
Possible values
0: Off
1: On
1: Heat
2: Cool
3: Fan
4: Dry
5: Auto
1: Auto
2: Low
3: Mid
4: High
5: High+ (For H-Link only)
1: Low
2: Mid
3: High (For CSNET only)
1: Auto
2 .. 8: Pos1 .. Pos7
Cool: 19 .. 30°C / 66 .. 86°F
Heat: 17 .. 30°C / 63 .. 86°F
Possible values
Celsius: -50 .. 99°C
0-Analog Input
Fahrenheit: -58 .. 210°F
Celsius: 0 .. 200°C
0-Analog Input
Fahrenheit: 32 .. 392°F
