5.2. Connection
CAUTION
Disconnect all systems from power before manipulating and connecting them to the gateway.
IMPORTANT
Keep communication cables away from power and ground wires.
5.2.1. Gateway Connectors
Page 10 of 38
Figure 5. Wiring diagram
