Hitachi VRF with KNX, Serial and IP support
Table 6. Outdoor units signals
Object name
Status_Communication Error OU
Status_Outdoor Air Temperature (°C)
Status_Compresor Top Temperature (°C)
Status_Total Real Compresor Freq.
Status_Total Compresor Current
Status_Out Exp. Valve 1 Open
Status_Discharge Pressure
Status_Suction Pressure
Table 7. Indoor units signals
Object name
Control_On/Off
Status_On/Off
Control_Operation mode
Status_Operation mode
Control_Operation mode
Status_Operation mode
Control_Mode Cool/Heat
Status_Mode Cool/Heat
Control_Heat mode&ON
Control_Cool mode&ON
Control_Auto mode
Status_Auto mode
Page 26 of 38
Possible values
0: No error
1.005-DPT_Alarm (1bit)
1: Error
Celsius: -50 .. 99 °C
9.001-DPT_Value_Temp (2byte)
Fahrenheit: -58 .. 210°F
Celsius: 0 .. 200 °C
9.001-DPT_Value_Temp (2byte)
Fahrenheit: 32 .. 392°F
0 .. 255 Hz 14.033-DPT_Value_Frequency (4byte)
0 .. 255 A 14.019-DPT_Value_Electric_Current (4byte)
0 .. 100% 5.001: percentage (0..100%) (1 byte)
-5.0 .. 9.9 Mpa 14.058: pressure (Pa) (4byte)
-5.0 .. 9.9 Mpa 14.058: pressure (Pa) (4byte)
Possible values
0: Off
1: On
0: Off
1: On
0: Auto
1: Heat
3: Cool
9: Fan
14: Dry
0: Auto
1: Heat
3: Cool
9: Fan
14: Dry
0: Auto
1: Heat
2: Dry
3: Fan
4: Cool
0: Auto
1: Heat
2: Dry
3: Fan
4: Cool
0: Cool
1: Heat
0: Cool
1: Heat
0 %: Off
1 .. 100 %: On+Heat
0%: Off
1 .. 100 %: On+Cool
1: Set auto mode
1: Auto mode active
0: Auto mode not active
Integration into KNX Systems
DPT
DPT
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
20.105-DPT_HVACContrMode (1byte)
20.105-DPT_HVACContrMode (1byte)
5.x (1byte)
5.x (1byte)
1.100-DPT_Heat/Cool (1bit)
1.100-DPT_Heat/Cool (1bit)
5.001-DPT_Scaling (1byte)
5.001-DPT_Scaling (1byte)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
USER MANUAL Version 1.0.6
Flags
R, T
R, T
R, T
R, T
R, T
R, T
R, T
R, T
Flags
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
Ri, W, U
Ri, W, U
R, T
