Integration into KNX Systems
Object name
Control_Heat mode
Status_Heat mode
Control_Cool mode
Status_Cool mode
Control_Fan mode
Status_Fan mode
Control_Dry mode
Status_Dry mode
Control_Fan speed enumerated
Status_Fan speed enumerated
Control_Fan speed scaling
Status_Fan speed scaling
Control_Fan speed low
Status_Fan speed low
Control_Fan speed mid
Status_Fan speed mid
Control_Fan speed high
Status_Fan speed high
Control_Fan speed high+
Status_Fan speed high+
Control_Fan speed Man/Auto
Status_Fan speed Man/Auto
Control_Vane position enumerated
Status_Vane position enumerated
USER MANUAL Version 1.0.6
Possible values
1: Set heat mode
1: Heat mode active
0: Heat mode not active
1: Set cool mode
1: Cool mode active
0: Cool mode not active
1: Set fan mode
1: Fan mode active
0: Fan mode not active
1: Set dry mode
1: Dry mode active
0: Dry mode not active
1: Low
2: Mid
3: High
4: High+
1: Low
2: Mid
3: High
4: High+
Thersholds:
0 .. 37 %
38 .. 62 %
63 .. 87 %
88 .. 100 %
Thersholds:
25 %
50 %
75 %
100 %
1: Set fan speed low
1: Speed low active
0: Speed low not active
1: Set fan speed mid
1: Speed mid active
0: Speed mid not active
1: Set fan speed high
1: Speed high active
0: Speed high not active
1: Set fan speed high+
1: Speed high+ active
0: Speed high+ not active
0: Manual
1: Auto
0: Manual
1: Auto
1 .. 7: Position 1 .. Position 7
1 .. 7: Position 1 .. Position 7
Hitachi VRF with KNX, Serial and IP support
DPT
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
5.010 (DPT_Value_1_Ucount)
5.010 (DPT_Value_1_Ucount)
5.001-DPT_Scaling (1byte)
5.001-DPT_Scaling (1byte)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
5.010 (DPT_Value_1_Ucount)
5.010 (DPT_Value_1_Ucount)
Flags
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
