Mounting
DIN rail mounting
1.
Fit the gateway's top-side clips in the upper edge of the DIN rail.
2.
Press the low side of the gateway gently to lock it in the DIN rail.
3.
Make sure the gateway is firmly fixed.
NOTE
For some DIN rails, to complete step 2, you may need a small screwdriver or similar to pull the
bottom clip down.
USER MANUAL Version 1.0.6
Hitachi VRF with KNX, Serial and IP support
Page 9 of 38
