Integration into KNX Systems

6.2. Integration into KNX Systems

6.2.1. KNX Signals

The following tables list all available KNX signals for this gateway.
NOTE
Physical Address: The gateway supports (P/S) and (P/I/S) format levels.
NOTICE
Communication object flags:
• Ri (Read on initialization): The gateway requests this signal's updated data after an initialization
instead of waiting for a change in the signal.
• R: The KNX system can read this signal.
• W: The KNX system can write this signal.
• T: The KNX system receives a telegram when this signal changes its value.
• U: This signal's data is updated after a reboot of either the gateway or the bus.
Table 5. Global signals
Object name
On/Off (all units)
Operating Mode (all units)
Operating Mode (all units)
Fan Speed (all units)
Fan Speed AUTO (all units)
Air louver position (all units)
Air louver position AUTO (all units)
Temperature Setpoint (°C) (all units)
USER MANUAL Version 1.0.6
Possible values
0: Off
1: On
0: Auto
1: Heat
3: Cool
9: Fan
14: Dry
0: Auto
1: Heat
2: Dry
3: Fan
4: Cool
1: Low
2: Mid
3: High
4: High+
1: Set auto fan
0-: auto fan
1 .. 7: Position 1 .. Position 7
1: Set auto vane
0:Stop auto vane
Cool: 19 .. 30°C / 66 .. 86°F
Heat: 17 .. 30°C / 62 .. 86°F
Hitachi VRF with KNX, Serial and IP support
DPT
1.001-DPT_Switch (1bit)
20.105-DPT_HVACContrMode (1byte)
5.x (1byte)
5.x (1byte)
1.001-DPT_Switch (1bit)
5.x (1byte)
1.001-DPT_Switch (1bit)
9.001-DPT_Value_Temp (2byte)
Flags
W
W
W
W
W
W
W
W
Page 25 of 38
