HMS Networks Intesis IN770AIR00XO000 User Manual page 33

Hitachi VRF with KNX, Serial and IP support
Object name
Status_Operation condition
Status_RC SW Temperature
Status_RC SW Configuration
Status_Consumption Yesterday
Status_Consumption Today
Status_Consumption Total
Status_Consumption Yesterday Heat
Status_Consumption Today Heat
Status_Consumption Total Heat
Status_Consumption Yesterday Cool
Status_Consumption Today Cool
Status_Consumption Total Cool
NOTE
The default unit for the consumption signals is Wh, but you can set it in KWh instead. If so, the DPT
number changes from 13.010 to 13.013.
Page 30 of 38
Possible values
0: Off
1: Thermo Off
2: Thermo On
3: Alarm
Celsius: -63 .. 63 °C
Fahrenheit: -81 .. 145°F
0: Without RCS
1: With RCS
Wh/KWh
Wh/KWh
Wh/KWh
Wh/KWh
Wh/KWh
Wh/KWh
Wh/KWh
Wh/KWh
Wh/KWh
Integration into KNX Systems
DPT
5.x (1byte)
9.001-DPT_Value_Temp (2byte)
1.001-DPT_Switch (1bit)
13.010 active energy (Wh) (4byte)
13.010 active energy (Wh) (4byte)
13.010 active energy (Wh) (4byte)
13.010 active energy (Wh) (4byte)
13.010 active energy (Wh) (4byte)
13.010 active energy (Wh) (4byte)
13.010 active energy (Wh) (4byte)
13.010 active energy (Wh) (4byte)
13.010 active energy (Wh) (4byte)
USER MANUAL Version 1.0.6
Flags
R, T
R, T
R, T
R, T
R, T
R, T
R, T
R, T
R, T
R, T
R, T
R, T
