Hitachi VRF with KNX, Serial and IP support
Object name
Control_Vane position scaling
Status_Vane position scaling
Control_Vane position auto
Status_Vane position auto
Control_Vane position-1
Status_Vane position-1
Control_Vane position-2
Status_Vane position-2
Control_Vane position-3
Status_Vane position-3
Control_Vane position-4
Status_Vane position-4
Control_Vane position-5
Status_Vane position-5
Control_Vane position-6
Status_Vane position-6
Control_Vane position-7
Status_Vane position-7
Control_Temperature Setpoint
Status_Temperature Setpoint
Status_AC Ambient Temperature
Status_Remote Sensor Temperature
Control_KNX ambient Temperature
Page 28 of 38
Possible values
Thersholds:
0 .. 21 %
22 .. 36 %
37 .. 50 %
51 .. 64 %
65 .. 79 %
80 .. 93 %
94 .. 100 %
Thersholds:
0 .. 14 %
15 .. 29 %
30 .. 43 %
44 .. 57 %
58 .. 71 %
72 .. 86 %
87 .. 100 %
1: Set auto vane
0: Stop auto vane
1: Vane auto active
0: Vane auto not active
1: Set position-1 vane
1: Vane position-1 active
0: Vane position-1 not active
1: Set position-2 vane
1: Vane position-2 active
0: Vane position-2 not active
1: Set position-3 vane
1: Vane position-3 active
0: Vane position-3 not active
1: Set position-4 vane
1: Vane position-4 active
0: Vane position-4 not active
1: Set position-5 vane
1: Vane position-5 active
0: Vane position-5 not active
1: Set position-6 vane
1: Vane position-6 active
0: Vane position-6 not active
1: Set position-7 vane
1: Vane position-7 active
0: Vane position-7 not active
Cool: 19 .. 30°C / 66 .. 86°F
Heat: 17.. 30°C / 62 .. 86°F
Cool: 19 .. 30°C / 66 .. 86°F
Heat: 17 .. 30°C / 62 .. 86°F
Celsius: -63 .. 63 °C
Fahrenheit: -81 .. 145°F
Celsius: -63 .. 63 °C
Fahrenheit: -81 .. 145°F
°C / °F
Integration into KNX Systems
DPT
5.001-DPT_Scaling (1byte)
5.001-DPT_Scaling (1byte)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
9.001-DPT_Value_Temp (2byte)
9.001-DPT_Value_Temp (2byte)
9.001-DPT_Value_Temp (2byte)
9.001-DPT_Value_Temp (2byte)
9.001-DPT_Value_Temp (2byte)
USER MANUAL Version 1.0.6
Flags
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
R, T
R, T
Ri, W, U
