HMS Networks Intesis IN770AIR00XO000 User Manual page 35

Hitachi VRF with KNX, Serial and IP support
Object name
OUXX_Total Real Comp. Freq.
OUXX_Total Comp. Current
OUXX_Out Exp. Valve 1 Open
OUXX_Discharge Pressure
OUXX_Suction Pressure
OUXX_Communication Status
Table 10. Indoor units signals
Object name
OXXUXX_On/Off_S
OXXUXX_On/Off_C
OXXUXX_Mode_S
OXXUXX_Mode_C
OXXUXX_Setpoint_S
OXXUXX_Setpoint_C
OXXUXX_FanSpeed_S
OXXUXX_FanSpeed_C
OXXUXX_Air louver Position_S
OXXUXX_Air louver Position_C
OXXUXX_Remote Sensor Temp.
OXXUXX_Inlet Temp.
OXXUXX_Outlet Temp.
OXXUXX_GasPipe Temp.
Page 32 of 38
Possible values
0 .. 255 Hz 0-Analog Input
0 .. 255 A 0-Analog Input
0 ..100% 0-Analog Input
-5.0 .. 9.9 MPa 0-Analog Input
-5.0 .. 9.9 MPa 0-Analog Input
0: Not Exit
3-Binary Input
1: Exist
Possible values
0: Off
1: On
0: Off
1: On
1: Heat
2: Cool
3: Fan
4: Dry
5: Auto
1: Heat
2: Cool
3: Fan
4: Dry
5: Auto
Cool: 19 .. 30°C / 66 .. 86°F
Heat: 17 .. 30°C / 63 .. 86°F
Cool: 19 .. 30°C / 66 .. 86°F
Heat: 17 .. 30°C / 63 .. 86°F
1: Auto
2: Low
3: Mid
4High
5: High+ (For H-Link only)
1: Auto
2: Low
3: Mid
4High 5: High+ (For H-Link only)
1: Auto
2 .. 8: Pos1 .. Pos7
1: Auto
2 .. 8: Pos1 .. Pos7
Celsius: -63 .. 63°C
Fahrenheit: -81 .. 145°F
Celsius: -63 .. 63°C
Fahrenheit: -81 .. 145°F
Celsius: -63 .. 63°C
Fahrenheit: -81 .. 145°F
Celsius: -63 .. 63°C
Fahrenheit: -81 .. 145°F
Integration into BACnet Systems
Object type Object instance
(OU address × 25) + 20000 + 2
(OU address × 25) + 20000 + 3
(OU address × 25) + 20000 + 4
(OU address × 25) + 20000 + 5
(OU address × 25) + 20000 + 6
(OU address × 25) + 20000 + 0
Object type Object instance
3-Binary Input (IU address × 100) + 0
4-Binary Output (IU address × 100) + 0
13-Multistate Input (IU address × 100) + 0
14-Multistate Output (IU address × 100) + 0
0-Analog Input (IU address × 100) + 0
1-Analog Output (IU address × 100) + 0
13-Multistate Input (IU address × 100) + 1
14-Multistate Output (IU address × 100) + 1
13-Multistate Input (IU address × 100) + 2
14-Multistate Output (IU address × 100) + 2
0-Analog Input (IU address × 100) + 1
0-Analog Input (IU address × 100) + 2
0-Analog Input (IU address × 100) + 3
0-Analog Input (IU address × 100) + 4
USER MANUAL Version 1.0.6
