  • Page 1 ENGLISH Daikin HVAC Gateway with KNX, Serial, and IP Support IN770AIR⁎⁎⁎O000 GATEWAY USER MANUAL Version 1.0.0 Publication date 2024-06-17...
  • Page 2 The information in this document shall therefore not be construed as a commitment on the part of HMS Networks and is subject to change without notice. HMS Networks makes no commitment to update or keep current the information in this document.

  • Page 3: Table Of Contents

    Daikin HVAC Gateway with KNX, Serial, and IP Support Table of Contents 1. Description, Compatible AC systems, and Order Codes ..............1 2. Licensing ..........................2 3. General Information ........................ 3 3.1. Intended Use of the User Manual ..................3 3.2.

  • Page 4: Description, Compatible Ac Systems, And Order Codes

    Description, Compatible AC systems, and Order Codes Daikin HVAC Gateway with KNX, Serial, and IP Support 1. Description, Compatible AC systems, and Order Codes IN770AIR⁎⁎⁎O000 Gateway. Modbus®, KNX®, BACnet®, and Home Automation gateway for Daikin® HVAC systems. Use the compatibility tool to get a complete list of compatible AC units: https://compatibility.intesis.com/# ORDER CODE LEGACY ORDER CODE...

  • Page 5: Licensing

    Daikin HVAC Gateway with KNX, Serial, and IP Support Licensing 2. Licensing Distribution license(s) for the IN770AIR⁎⁎⁎O000 gateway: Maximum AC units Order Code License Indoor units Outdoor units IN770AIRXXSO000 IN770AIR00SO000 Small IN770AIR00MO000 Medium NOTE The order code may vary depending on the product seller and the buyer's location. Page 2 of 43 USER MANUAL Version 1.0.0...

  • Page 6: General Information

    General Information Daikin HVAC Gateway with KNX, Serial, and IP Support 3. General Information 3.1. Intended Use of the User Manual This manual contains the main features of this gateway and the instructions for its appropriate installation, configuration, and operation. The contents of this manual should be brought to the attention of any person who installs, configures, or operates this gateway or any associated equipment.

  • Page 7: Admonition Messages And Symbols

    Daikin HVAC Gateway with KNX, Serial, and IP Support Admonition Messages and Symbols This Intesis gateway is designed for installation in an enclosure. When the device is mounted outside an enclosure, precautions should be taken to avoid electrostatic discharges to the unit in environments with static levels above 4 kV.

  • Page 8: Overview

    Overview Daikin HVAC Gateway with KNX, Serial, and IP Support 4. Overview This IN770AIR⁎⁎⁎O000 gateway supports four combinations. Gateway's client interface ↔ Gateway's server interface Modbus TCP and RTU KNX TP Daikin HVAC systems BACnet/IP or MS/TP Home Automation IMPORTANT This document assumes that the user is familiar with these technologies.

  • Page 9: Inside The Package

    Daikin HVAC Gateway with KNX, Serial, and IP Support Inside the Package Figure 3. Integration of Daikin AC systems into BACnet installations Figure 4. Integration of Daikin AC systems into Home Automation installations 4.1. Inside the Package Items included: • Intesis IN770AIR⁎⁎⁎O000 Gateway •...

  • Page 10: Gateway General Functionality

    Gateway General Functionality Daikin HVAC Gateway with KNX, Serial, and IP Support • DIN rail and wall mounting case. • Accredited with the main certifications for electronic equipment. • Three binary inputs to integrate energy meters. • Multiple ports for serial and TCP/IP communication: –...

  • Page 11: Quick Start Guide

    Daikin HVAC Gateway with KNX, Serial, and IP Support Quick Start Guide 5. Quick Start Guide IMPORTANT While the following procedure outlines the fundamental steps for installing, wiring, and configuring the gateway, it is crucial to thoroughly review all documentation to prevent errors. Install Intesis MAPS on your laptop.

  • Page 12: Hardware

    Hardware Daikin HVAC Gateway with KNX, Serial, and IP Support 6. Hardware 6.1. Mounting IMPORTANT Before mounting, please ensure that the chosen installation place preserves the gateway from direct solar radiation, water, high relative humidity, or dust. NOTE Mount the gateway on a wall or over a DIN rail. We recommend the DIN rail mounting option, preferably inside a grounded metallic industrial cabinet.
  • Page 13 Daikin HVAC Gateway with KNX, Serial, and IP Support Mounting DIN rail mounting Keep the clips in their original position. Fit the gateway’s top-side clips in the upper edge of the DIN rail. Press the low side of the gateway gently to lock it in the DIN rail. Make sure the gateway is firmly fixed.

  • Page 14: Connection

    Connection Daikin HVAC Gateway with KNX, Serial, and IP Support 6.2. Connection CAUTION Disconnect all systems from power before manipulating and connecting them to the gateway. IMPORTANT Keep communication cables away from power and ground wires. 6.2.1. Gateway Connectors Figure 5. Wiring diagram USER MANUAL Version 1.0.0 Page 11 of 43...
  • Page 15 Daikin HVAC Gateway with KNX, Serial, and IP Support Connection Connectors' wiring: IMPORTANT For all connectors, use solid or stranded wires (twisted or with ferrule). Cross-section/gauge per terminal: • One core: 0.2 .. 2.5 mm / 24 .. 11 AWG •...

  • Page 16: Connection Procedure For The Ac Unit

    Connection Daikin HVAC Gateway with KNX, Serial, and IP Support IMPORTANT • Use SELV-rated NEC class 2 or limited power source (LPS) power supply. • Respect the polarity. • Connect the gateway's ground terminal to the installation grounding. IMPORTANT To avoid earth loops that can damage the gateway and/or any other equipment connected to it, we strongly recommend: •...

  • Page 17: Connection Procedure For Knx

    Daikin HVAC Gateway with KNX, Serial, and IP Support Connection The connector for the EIA-485 bus is a green pluggable terminal block labeled SG (signal ground), B-, and A+. IMPORTANT Observe polarity. IMPORTANT Remember the characteristics of the standard EIA-485 bus: •...
  • Page 18 Connection Daikin HVAC Gateway with KNX, Serial, and IP Support • Connecting to a hub or switch of the LAN of the building: use a straight Ethernet UTP/FTP CAT5 or higher cable. NOTE When commissioning the gateway for the first time, DHCP will be enabled for 30 seconds. During that time, if there is a DHCP server, an IP address will be automatically assigned to the gateway.

  • Page 19: Connection Procedure For Home Automation

    Daikin HVAC Gateway with KNX, Serial, and IP Support Connection 6.2.6. Connection Procedure for Home Automation Connect the Home Automation Ethernet cable to the gateway's Ethernet Port. The correct cable to use depends on where the gateway is connected: • Connecting directly to a Home Automation device: use a crossover Ethernet UTP/FTP CAT5 or higher cable. •...

  • Page 20: Gateway Layout

    Gateway Layout Daikin HVAC Gateway with KNX, Serial, and IP Support 6.3. Gateway Layout Figure 6. Disposition of hardware elements in the gateway Plastic covers numbered in the image as ①, ②, ③, and ④ can be easily disassembled. The following sections explain each element in more detail: LEDs, DIP switches, and the push button. USER MANUAL Version 1.0.0 Page 17 of 43...

  • Page 21: Led Indicators

    Daikin HVAC Gateway with KNX, Serial, and IP Support LED Indicators 6.4. LED Indicators Table 1. LEDs location and behavior Cover Color Description Top side LED 1 (PWR) Green Power on (not programmable) LED 2 (ERR) Blinking: Hardware error Under frontal cover ① LED 3 Green 485 Tx (RS485 for Modbus)

  • Page 22: Push Button

    Push Button Daikin HVAC Gateway with KNX, Serial, and IP Support 6.6. Push Button Find the push button at the top side, between the KNX and the Ethernet connectors (see the figure Disposition of hardware elements in the gateway (page 17)).

  • Page 23: Technical Specifications

    Daikin HVAC Gateway with KNX, Serial, and IP Support Technical Specifications 6.7. Technical Specifications Plastic, type PC (UL 94 V-0). Color: Light Grey. RAL 7035 Housing Net dimensions (HxWxD): Millimeters: 90 x 106 x 58 mm / Inches: 3.5 x 4.2 x 2.3" Wall: Use M3 25 mm (1") length screws.

  • Page 24: Dimensions

    Dimensions Daikin HVAC Gateway with KNX, Serial, and IP Support 6.8. Dimensions • Net dimensions (HxWxD) Millimeters: 90 x 106 x 58 mm Inches: 3.5 x 4.2 x 2.3" IMPORTANT Leave enough clear space to wire the gateway easily and for the subsequent manipulation of elements.

  • Page 25: Available Protocol Combinations

    Daikin HVAC Gateway with KNX, Serial, and IP Support Available Protocol Combinations 7. Available Protocol Combinations 7.1. Integration into Modbus Systems 7.1.1. Modbus Registers NOTICE This part is common for Modbus RTU and TCP. Functions to read Modbus registers: • 03 Read Holding Registers. •...
  • Page 26 Integration into Modbus Systems Daikin HVAC Gateway with KNX, Serial, and IP Support Register name Possible values Modbus address Vane Position 2 (all units) 1: Set Position 2 Vane Position 3 (all units) 1: Set Position 3 Vane Position Vertical (all units) 1: Set Vane Position Vertical Vane Position Stop (all units) 1: Set Vane Position Stop...
  • Page 27 Daikin HVAC Gateway with KNX, Serial, and IP Support Integration into Modbus Systems Register name Possible values Modbus address formula 1: Fix 2: 2 step Indoor_Unit_Capability Fan speed steps 3: 3 step (IU address[1 .. 64] × 200 + 8 4: 4 step 5: 5 step 0: Not exist...
  • Page 28 Integration into Modbus Systems Daikin HVAC Gateway with KNX, Serial, and IP Support Register name Possible values Modbus address formula 0: Off Quiet_mode Low noise On/Off (IU address[1 .. 64] × 200 + 35 1: On Domestic_hot_water Storage setpoint (x10°C) -127.9°C ..

  • Page 29: Integration Into Knx Systems

    Daikin HVAC Gateway with KNX, Serial, and IP Support Integration into KNX Systems 7.2. Integration into KNX Systems 7.2.1. KNX Signals The following tables list all available KNX signals for this gateway. NOTE Physical Address: The gateway supports (P/S) and (P/I/S) format levels. NOTICE Communication object flags: •...
  • Page 30 Integration into KNX Systems Daikin HVAC Gateway with KNX, Serial, and IP Support Object name Possible values Flags Domestic_hot_water Storage setpoint (°C) (all units) -127.9°C .. 127.9°C 9.001-DPT_Value_Temp (2byte) 0: No meaning Ventilation operation mode (all units) 1: Auto 5.x (1byte) *Only available for compaitble VAM models from the HRV series.
  • Page 31 Daikin HVAC Gateway with KNX, Serial, and IP Support Integration into KNX Systems Object name Possible values Flags 0: Heat mode not active Status_Heat mode 1.001-DPT_Switch (1bit) 1: Heat mode active Control_Cool mode 1: Set cool mode 1.001-DPT_Switch (1bit) 0: Cool mode not active Status_Cool mode 1.001-DPT_Switch (1bit) 1: Cool mode active...
  • Page 32 Integration into KNX Systems Daikin HVAC Gateway with KNX, Serial, and IP Support Object name Possible values Flags 0: Speed Auto not active Status_Fan speed Auto 1.001-DPT_Switch (1bit) 1: Speed Auto active 0: Horizontal 1: P1 2: P2 Control_Vane position enumerated 3: P3 5.x (1byte) 4: Vertical...
  • Page 33 Daikin HVAC Gateway with KNX, Serial, and IP Support Integration into KNX Systems Object name Possible values Flags Control_Vane position-vertical 1: Set position-vertical 1.001-DPT_Switch (1bit) 0: Vane position-vertical not active Status_Vane position-Vertical 1.001-DPT_Switch (1bit) 1: Vane position-vertical active Control_Vane position-swing 1: Set position-swing vane 1.001-DPT_Switch (1bit) 0: Vane position-swing not active...
  • Page 34 Integration into KNX Systems Daikin HVAC Gateway with KNX, Serial, and IP Support Object name Possible values Flags Status_Heating water setpoint -127.9°C .. 127.9°C 9.001-DPT_Value_Temp (2byte) Control_Cooling water setpoint -127.9°C .. 127.9°C 9.001-DPT_Value_Temp (2byte) Status_Cooling water setpoint -127.9°C .. 127.9°C 9.001-DPT_Value_Temp (2byte) Control_KNX ambient Temperature (°C) °C...
  • Page 35 Daikin HVAC Gateway with KNX, Serial, and IP Support Integration into KNX Systems Object name Possible values Flags Status_Unit adress 0 .. 15 5.x (1byte) Status_Line adress 0 .. 3 5.x (1byte) Status_Consumption Yesterday Wh/KWh See NOTE Status_Consumption Today Wh/kWh See NOTE Status_Consumption Total Wh/kWh...

  • Page 36: Integration Into Bacnet Systems

    Integration into BACnet Systems Daikin HVAC Gateway with KNX, Serial, and IP Support 7.3. Integration into BACnet Systems NOTICE You can see the Protocol Implementation Conformance Statement (PICS) document here. 7.3.1. BACnet Objects NOTICE This part is common for BACnet MS/TP and BACnet/IP. Input object types: •...
  • Page 37 Daikin HVAC Gateway with KNX, Serial, and IP Support Integration into BACnet Systems Object name Possible values Object type Object instance 0: Off OXXUXX_On/Off_C 4-Binary Output (IU address[1 .. 64] × 100) + 0 1: On 0: Off OXXUXX_On/Off_S 3-Binary Input (IU address[1 ..
  • Page 38 Integration into BACnet Systems Daikin HVAC Gateway with KNX, Serial, and IP Support Object name Possible values Object type Object instance OXXUXX_TemperatureSetpoint_S -127.9 .. 127.9°C 0-Analog Input (IU address[1 .. 64] × 100) + 0 OXXUXX_RoomTemperature -127.9 .. 127.9°C 0-Analog Input (IU address[1 ..
  • Page 39 Daikin HVAC Gateway with KNX, Serial, and IP Support Integration into BACnet Systems Object name Possible values Object type Object instance 0: Off OXXUXX_StatusIndoor_Heater 3-Binary Input (IU address[1 .. 64] × 100) + 14 1: On 0: Slave OXXUXX_StatusIndoor_Cool/Heat_Master 3-Binary Input (IU address[1 ..
  • Page 40 Integration into BACnet Systems Daikin HVAC Gateway with KNX, Serial, and IP Support Object name Possible values Object type Object instance OXXUXX_Consumption_Yesterday_Cool kWh/Wh 0-Analog Input (IU address[1 .. 64] × 100) + 11 OXXUXX_Consumption_Today_Cool kWh/Wh 0-Analog Input (IU address[1 .. 64] × 100) + 12 OXXUXX_Consumption_Total_Cool kWh/Wh 0-Analog Input...

  • Page 41: Integration Into Home Automation Systems

    Daikin HVAC Gateway with KNX, Serial, and IP Support Integration into Home Automation Systems 7.4. Integration into Home Automation Systems 7.4.1. Home Automation Signals The following tables list all available Home Automation signals for this gateway. NOTE • SET: Command used to control the indoor unit. It is sent by the client. •...

  • Page 42: Late Configuration: Change The Gateway's Protocol

    Late Configuration: Change the Gateway's Protocol Daikin HVAC Gateway with KNX, Serial, and IP Support 8. Late Configuration: Change the Gateway's Protocol Reconfiguring the gateway with a different protocol is very easy: Connect the gateway to the PC and open the configuration tool Intesis MAPS. Select the new template you need.

  • Page 43: Error Codes

    Daikin HVAC Gateway with KNX, Serial, and IP Support Error Codes 9. Error Codes Table 7. Daikin error codes Error in the remote Error code Error codeM Error category Error description controller CommError Communication Error between the AC unit and the gateway External protection devices activated Indoor unit PCB assembly failure Interlock error for fan...
  • Page 44 Error Codes Daikin HVAC Gateway with KNX, Serial, and IP Support Error in the remote Error code Error codeM Error category Error description controller Ice thermal storage unit error Malfunctions in a sensor system Air temperature thermistor error Sensor system of power supply error High Pressure switch is faulty Low pressure switch is faulty Compressor motor overload sensor is abnormal...
  • Page 45 Daikin HVAC Gateway with KNX, Serial, and IP Support Error Codes Error in the remote Error code Error codeM Error category Error description controller Power transistor error Communication error between inverter and outdoor control unit Shortage of refrigerant (thermal storage unit) Power voltage imbalance, open phase Sensor error of temperature rise in a switch box Radiation fin temperature sensor error...
  • Page 46 Error Codes Daikin HVAC Gateway with KNX, Serial, and IP Support Error in the remote Error code Error codeM Error category Error description controller Inverter system error (supply air side) Inverter system error (return air side) Humidifying valve error Chilled water valve error Hot water valve error Heat exchanger of chilled water error Heat exchanger of hot water error...
