Integration into Modbus Systems
Register name
Inlet Temp. (x10°C)
Outlet Temp. (x10°C)
GasPipe Temp. (x10°C)
LiquidPipe Temp. (x10°C)
Unit Error code
Filter Alarm
Filter Alarm Reset
Communication Status
Allow On/Off from RC
Allow Mode from RC
Allow Setpoint from RC
Allow Fan from RC
Unit type
Unit Address
System Address
Dehumidification
Dehumidification Correction
Compresor Stop Cause
IDU expansion valve
Operation Condition
RC SW Temperature
RC SW Config
Consumption Yesterday
Consumption Today
Consumption Total
USER MANUAL Version 1.0.6
Possible values
Celsius: -63 .. 63°C
Celsius: -81 .. 145°F
Celsius: -63 .. 63°C
Celsius: -81 .. 145°F
Celsius: -63 .. 63°C
Celsius: -81 .. 145°F
Celsius: -63 .. 63°C
Celsius: -81 .. 145°F
Error code
0: Normal
1: Alarm
1: Reset
0: Not Exist
1: Exist
0: Allow
1: Not allow
0: Allow
1: Not allow
0: Allow
1: Not allow
0: Allow
1: Not allow
0: Not Defined
1: SS
2: FC
3: VRF
4: IU,
-ES
0 .. 63
0 .. 63
0: Disabled
1: Enabled
0: 0
1: (-1)
2: (-2)
255-Operation Off
Any other value: See the AC user manual
0 .. 100%
0: Off
1: Thermo Off
2: Thermo On
3: Alarm
Celsius: -63 .. 63°C
Fahrenheit: -81 .. 145°F
0: Without RCS
1: With RCS
Wh/KWh
Wh/KWh
Wh/KWh
Hitachi VRF with KNX, Serial and IP support
Modbus address formula
(IU address[0 .. 63]*100)+6
(IU address[0 .. 63]*100)+7
(IU address[0 .. 63]*100)+8
(IU address[0 .. 63]*100)+9
(IU address[0 .. 63]*100)+10
(IU address[0 .. 63]*100)+11
(IU address[0 .. 63]*100)+12
(IU address[0 .. 63]*100)+13
(IU address[0 .. 63]*100)+14
(IU address[0 .. 63]*100)+15
(IU address[0 .. 63]*100)+16
(IU address[0 .. 63]*100)+17
(IU address[0 .. 63]*100)+18
(IU address[0 .. 63]*100)+19
(IU address[0 .. 63]*100)+20
(IU address[0 .. 63]*100)+21
(IU address[0 .. 63]*100)+22
(IU address[0 .. 63]*100)+23
(IU address[0 .. 63]*100)+24
(IU address[0 .. 63]*100)+25
(IU address[0 .. 63*100)+26
(IU address[0 .. 63]*100)+27
(IU address[0 .. 63]*100)+28
(IU address[0 .. 63]*100)+30
(IU address[0 .. 63]*100)+32
