Integration into KNX Systems

6.2. Integration into KNX Systems

6.2.1. KNX Signals

The following tables list all available KNX signals for this gateway.
NOTE
Physical Address: The gateway supports (P/S) and (P/I/S) format levels.
NOTICE
Communication object flags:
• Ri (Read on initialization): The gateway requests this signal's updated data after an initialization
instead of waiting for a change in the signal.
• R: The KNX system can read this signal.
• W: The KNX system can write this signal.
• T: The KNX system receives a telegram when this signal changes its value.
• U: This signal's data is updated after a reboot of either the gateway or the bus.
Table 3. Global signals
Object name
Control_On/Off (all units)
Control_Operating Mode (all units)
Control_Operating Mode (all units)
Control_Operating Mode (all units)
Control_Fan Speed (all units)
Control_Fan Speed AUTO (all units)
Control_Setpoint (all the units)
Control_Operating Mode force (all the units)
Control_Remote Lock/Unlock (all the units)
Table 4. Individual units signals
Object name
Status_CommError
Control_On/Off
Status_On/Off
Control_Operation mode
Status_Operation mode
Control_Operation mode
Status_Operation mode
Control_Operation mode
Status_Operation mode
Control_Mode Cool/Heat
Status_Mode Cool/Heat
Control_Auto mode
Status_Auto mode
Control_Heat mode
Status_Heat mode
Control_Cool mode
USER MANUAL Version 1.0.1
Possible values
0-Off, 1-On
0-Auto, 1-Heat, 3-Cool, 9-Fan, 14-Dry
0-Auto, 1-Heat, 2-Dry, 3-Fan, 4-Cool
0-Cool, 1-Heat, 2-Fan, 3-Dry, 4-Auto
0-Low, 1-Mid, 2-High, 3-Powerful
1-Set auto fan; 0-Stop auto fan
17 .. 30ºC / 62 .. 86ºF
0-No force, 1-Force
0-Unlock, 1-Lock
Possible values
0-No error, 1-Error
0-Off, 1-On
0-Off, 1-On
0-Auto, 1-Heat, 3-Cool, 9-Fan, 14-Dry
0-Auto, 1-Heat, 3-Cool, 9-Fan, 14-Dry
0-Auto, 1-Heat, 2-Dry, 3-Fan, 4-Cool
0-Auto, 1-Heat, 2-Dry, 3-Fan, 4-Cool
0-Cool, 1-Heat, 2-Fan, 3-Dry, 4-Auto
0-Cool, 1-Heat, 2-Fan, 3-Dry, 4-Auto
0-Cool, 1-Heat
0-Cool, 1-Heat
1-Set auto mode
1-Auto mode active, 0-Auto mode not active
1-Set heat mode
1-Heat mode active, 0-Heat mode not active
1-Set cool mode
Midea commecial and VRF with KNX, Serial and IP support
DPT
1.001-DPT_Switch (1bit)
20.105-DPT_HVACContrMode (1byte)
5.x (1byte)
5.x (1byte)
5.x (1byte)
1.001-DPT_Switch (1bit)
9.001/9.027-DPT_Value_Temp (2byte)
1.002 DPT_Bool (1bit)
1.002 DPT_Bool (1bit)
DPT
1.005-DPT_Alarm (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
20.105-DPT_HVACContrMode (1byte)
20.105-DPT_HVACContrMode (1byte)
5.x (1byte)
5.x (1byte)
5.x (1byte)
5.x (1byte)
1.100-DPT_Heat/Cool (1bit)
1.100-DPT_Heat/Cool (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
1.001-DPT_Switch (1bit)
Flags
W
W
W
W
W
W
W
W
W
Flags
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
R, T
Ri, W, U
