Part 2: Carrier Board

Part 2.1: Introduction

Through the previous function introduction, you can understand the function of
the carrier board part.
 2-channel fiber interface
 1-channel PCIEx8 interface
 1-channel USB Uart interface
 1-channel Ethernet RJ45 interface
 3-Channel FMC interface
 1-channel Micro SD card slot
