10 Appendix A: System points

Points ID
00-01
00-02
00-03
00-04
00-05
00-06
00-07
00-08
00-09
00-10
00-11
04-01 through to 04-04
05-01 through to 05-24
06-01 through to 06-24
07-01 through to 07-24
14-01 through to 14-02
15-01 through to 15-08
17-01
17-02
17-03
17-04
17-05
17-06
17-07
17-08
17-09
18-01
18-02
18-03
page 47
Table 20: Diagnostic options
Description
Panel ToneAlert
Comm Disconnect
Fire LED
Supervisory LED
Trouble LED
Silenced LED
AC Power LED
LCD Backlight
Battery Trouble LED
Ground Fault LED
Disabled LED
Annunciator Points
Annunciator Points
Annunciator Points
Annunciator Points
NACs 1-2
IDCs 1-8
AC Fail
Aux Over Current
Positive Earth
Low Battery
Depleted Battery
Low Battery Cutout
Charger Trouble
Charger ON/OFF
Negative Earth
Unacked Fire
Unacked Supervisory
Unacked Trouble
2008 Foundation Series Fire Alarm Control Unit Operation Guide
Points ID
18-04
18-05
18-06
18-07
18-08
18-09
18-10
18-11
18-12
18-13
18-14
18-15
18-16
18-17
18-18
18-19
18-20
18-21
18-22
18-23
18-24 through to 18-30
18-31
18-32
22-01 through to 22-99
22-100 through to 22-113
23-01
23-02
23-03
Description
Extra Card
External Comm
Reserved
Cold Start
Warm Start
Time/Date not set
Service Mode
Key Inactive Disable
List Overflow
City/DACT Disc
City 1 Trouble
AHJ City Reset
Control Bypass
Elevator Bypass
Door Bypass
AV Tally Exceeded
WalkTest Active
Reserved
Programming Mode
Event Queue Overflow
Reserved
Sil/Rst Inhibit Actv
City 2 Trouble
Alarm Groups
Reserved
DACT Phone Line 1 Trouble
DACT Phone Line 2 Trouble
Central Station Communication
Trouble
