Cautions
READ AND SAVE THESE INSTRUCTIONS
and
followed to avoid damage to this product and associated equipment. Product operation and reliability depend upon proper
Warnings
installation.
DO NOT INSTALL ANY SIMPLEX® PRODUCT THAT APPEARS DAMAGED
inspect the contents of the carton for shipping damage. If damage is apparent, immediately file a claim with the carrier and notify
an authorized Simplex product supplier.
ELECTRICAL HAZARD
be performed by a representative or authorized agent of your local Simplex product supplier.
STATIC HAZARD
• Ground yourself before opening or installing components.
• Prior to installation, keep components wrapped in anti-static material at all times.
FCC RULES AND REGULATIONS – PART 15
device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a res-
idential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
SYSTEM REACCEPTANCE TEST AFTER SOFTWARE CHANGES -
accordance with NFPA-72, after any programming operation or change in site-specific software. Reacceptance testing is required after any change,
addition or deletion of system components, or after any modification, repair or adjustment to system hardware or wiring.
All components, circuits, system operations, or software functions known to be affected by a change must be 100% tested. In addition, to ensure that
other operations are not inadvertently affected, at least 10% of initiating devices that are not directly affected by the change, up to a maximum of 50
devices, must also be tested and proper system operation verified.
©2006-2011 SimplexGrinnell LP. All rights reserved.
Specifications and other information shown were current as of publication and are subject to change without notice.
Simplex and the Simplex logo are trademarks of Tyco International Ltd. and its affiliates and are used under license.
BMUX Comms Module (4100-6065),
4100U/4100ES to 2120 Audio and Phone
-
Follow the instructions in this installation manual. These instructions must be
- Disconnect electrical field power when making any internal adjustments or repairs. All repairs should
- Static electricity can damage components. Handle as follows:
- This equipment has been tested and found to comply with the limits for a Class A digital
firealarmresources.com
Riser Installation Instructions
- Upon unpacking your Simplex product,
To ensure proper system operation, this product must be tested in
579-805
Rev. D
Advertisement
Related Manuals for Simplex 4100-6065
Summary of Contents for Simplex 4100-6065
- Page 1 ©2006-2011 SimplexGrinnell LP. All rights reserved. Specifications and other information shown were current as of publication and are subject to change without notice. Rev. D Simplex and the Simplex logo are trademarks of Tyco International Ltd. and its affiliates and are used under license. firealarmresources.com...
- Page 2 The 4100U/4100ES BMUX Comms Module Introduction The Basic Multiplex Communications (BMUX Comms) Module (4100-6065) is used to interface existing 2120 transponders to the 4100U or 4100ES Fire Alarm Control Panel (FACP). As such, the module is essentially a physical media and protocol converter from 4100 Comms (RUI) to 2120 Comms (DC Loop).
-
Page 3: Status Indicating Leds
The 4100U/4100ES BMUX Comms Module, Continued Overview The BMUX Comms Module is a flat, 4x11 option module that plugs into the 4100U/4100ES power distribution interface. STATUS INDICATING LEDS Figure 1. BMUX Comms Module BMUX Comms The BMUX Comms Module has the following status indicating LEDs (see Table 1): Module LEDS Table 1: Status Indicating LEDs LED Name... - Page 4 The 4100U/4100ES BMUX Comms Module, Continued Requirements The BMUX Comms Module can communicate with up to 63 2120 transponders or DC Loop and Limitations peripheral devices. See Table 2 for the General System Specifications. Table 2: General System Specifications Electrical Specifications Module Input Voltage 24 VDC from FACP Current Consumption...
- Page 5 Installation of the Module into the 4100U/4100ES Overview The 4100-6065 BMUX Comms Module mounts on a PDI in a 4100U/4100ES expansion bay. It can be mounted on any available double vertical length block. Figure 2. BMUX Module Installation firealarmresources.com...
-
Page 6: Installation Procedures
Installation Procedures Install the Warning: Use a static control kit before you handle circuit boards and make sure to disconnect the 4100U/4100ES batteries from the system when you install the 4100U/4100ES circuit boards. Bays into the 2120 BMUX 1. Remove the 2120 BMUX equipment from the 2120 Backbox and remember to correctly label Backbox all wiring from the 2120 transponder(s) for use on the new 4100U/4100ES BMUX. - Page 7 Installation Procedures, Continued Setup 4. Verify the BMUX Comms Module properties within the Card Properties tab based on the job Procedures requirements (enter an available address - from 1 to 119 - in the Card Properties dialog before you set the card DIP switch). Figure 3.
- Page 8 Installation Procedures, Continued Setup 6. Build the new job (refer to the 4100ES Fire Alarm - Programmer’s Manual (574-849) for details Procedures on how to build the new job). Setting the Address 7. The module address is set via DIP Switch SW1, which is a bank of eight switches. From left to right (see the figure below) these switches are designated as SW1-1 through SW1-8.
- Page 9 Installation Procedures, Continued Setup Setting the Address, Continued Procedures Refer to the table below to configure the 4100U/4100ES BMUX Comms Module DIP switched with the proper address. Table 3: Switch Settings for Module Addresses Continued on next page firealarmresources.com...
- Page 10 Loop wiring. The jumper should normally be set to earth. Note: 0V shield may be required in certain installations as determined by the authorized Simplex technical representative (TR). 9. Download the Slave Exec files (BMUX Comms Module software, Flex-35 amp software, etc..), CPU Bootloader files, and the new CFIG file to the 4100U/4100ES FACP (refer to the 4100ES Fire Alarm - Programmer’s Manual (574-849) to download the software and refer to the...
- Page 11 Field Wiring to DC Loop Communications Channels Overview The DC Loop communications channel on the BMUX Comms Module can be wired in Style 4 or 6 configurations as illustrated in Figure 6. Pri + Pri - 4100U BMUX Comms Module Sec - Sec + Transponder...
- Page 12 Field Wiring to DC Loop Communications Channels, Continued Figure 7. Class A Style 6 Wiring Figure 8. Class B Style 4 Wiring Notes: 1. Maximum cable capacitance of 0.27uF or 126 Ohms total line pair resistance, whichever comes first. 2. DC Loop Communications maximum voltage 30Vdc, maximum short circuit current 150mA. 3.
- Page 13 2120 Audio System Upgrade Overview The BMUX typically contained the following audio components: • Master Microphone • Tone Generators • Preamplifiers • Preamp monitor modules • Message Players (tape or digital) • Audio control modules • Local BT I/O board for control and monitoring the audio system functions. An SCC adjacent to the 2120 was integral to the audio subsystem.
- Page 14 2120 Audio System Upgrade, Continued Overview The migration of the BMUX requires that Flex-35 amplifiers configured as power preamplifier(s) in the programmer (amplifier setup screen) be used to replace the power preamplifiers located in the adjacent SCC. The Power preamplifiers generate a 25V riser signal that is compatible with 25V supervision signal, and ignores shorts and opens on these circuits.
- Page 15 2120 Audio System Upgrade, Continued Note: Class A risers will not use the Class A NAC adapter card option on the Flex amplifier. Notes: 1. The SCC cabinet must be in the same room and within 20’ of the BMUX, and wired within rigid conduit. The 617-278 Class A monitor board, located in the SCC cabinet adjacent to the BMUX being replaced must be saved and re-wired as shown.
- Page 16 2120 Audio System Upgrade, Continued Class B Risers In a single channel Class B system, each 2120 amplifier supervises the riser. A monitor point local to the 2120 amplifier reports a loss of riser signal. Two channel Class B transponders are subdivided into Type 1 and Type 2 systems (see MUX2-11- 004).
- Page 17 2120 Audio System Upgrade, Continued Power The 2120 Power Preamplifier programmer card type will be restricted as to the options allowed: Preamplifier Configuration • Flex-35, 25V type only (4100-1312 or 4100-1326 only) Limitations • Class A NAC Adapter not allowed •...
- Page 18 1. Install the phone card into the 4100U/4100ES (see the Fire Fighter Phone System Installation Steps Instructions (579-226)). 2. Re-wire the riser to the 4100U/4100ES phone card (see the Fire Fighter Phone System Installation Instructions (579-226)). 3. Locate and replace the riser's EOLR with Simplex part # 733-894 (10K). firealarmresources.com...
- Page 19 firealarmresources.com...
- Page 20 579-805 Rev. D firealarmresources.com...
