Note: Elevator recall requires the following:
• The relay must have a function type of Primary or Alternate and must be wired to the appropriate elevator control contact.
• The IDC zones used to trigger elevator recall must be associated with the following alarm groups:
- Alarm Group 98: Associate all zones used to recall the elevator to the primary floor in this alarm group.
- Alarm Group 97: Associate all zones used to recall the elevator to the alternate floor in this alarm group.
9.3.2

Editing relay labels

To edit the relay label, use the following steps:
1. See the Editing relay function type
2. Use the UP and DOWN keys to scroll through the choices until [Edit Label] or [Clear Label] appears.
AUX2
Fn: [Edit Label]
Note: [Edit Label] preserves the existing label and enables editing. [Clear Label] deletes the existing label first and then
enables editing.
3. Press ENTER. A cursor appears beneath the leftmost letter of the currently assigned custom label. Use the LEFT and RIGHT
arrow keys to move the cursor between letters. The characters available for labels are:
A-Z 0-9 , blank space & ( ) * + - . / : ' # ! @ $ % ^ = ?
4. Press ENTER to accept any changes made and exit. Press ESC key to quit editing without saving. You can edit a label in one of
three ways:
- Using the Keypad. Press the alphanumeric key corresponding to the letter you want. For example, for the letter C, press the 2 key
on the keypad four times. Use the LEFT and RIGHT arrow keys to move to the next letter in the label.
- Use the UP and DOWN keys. Each time you press the NEXT key, the display advances to the next character. Likewise, each press of
the UP key moves backward one character. Use the LEFT and RIGHT arrow keys to move to the next letter in the label.
- Use the Word Library, which is a stored list of common words sorted alphabetically. Press MENU. The control unit displays the
following:
AUX2
<MENU>=Word Library
To jump to a word, press the alphanumeric key corresponding to the first letter in the word. For example, to use the word Floor,
press the 3 key repeatedly until
To access words beginning with the same letter use the UP and DOWN keys to select the word. See Table 9 for a list of all the words
in the library.
5. When relay programming is complete, press ESC key until the control unit displays the following:
[Cont] Dscrd Save
6. Select [Save] and press ENTER to save the configuration.
page 29
and repeat steps 1 to 6.
Floor
appears.
