Alarm groups

You can implement basic selective signaling applications with alarm groups.
When you program an input, such as a zone of smoke detectors, and output points, such as an NAC or relay, you can associate the point
with an alarm group number.
The number can range from 1 to 99 and each point can be in up to three alarm groups.
When programming is complete, an initiating device can trigger only the output devices such as relays or NACs that share its alarm groups.
9.8

Viewing and clearing historical logs

The control unit has four separate, non-volatile historical logs:
• Alarm
• Supervisory
• Trouble
• User
You can view historical logs separately, or you can view each log in chronological order as a single combined log. For different logs and their
stored events, see Table 16.
Each log records information about the event and the time the event occurred.
You can view logs at access level 1, but only an operator with a level 2 login or higher can clear logs.
Historical log
ALOG (Alarm Log 100 entries)
Supervisory Log (100 entries)
TLOG (Trouble Log 300 entries)
User Log (100 entries)
CLOG (Combined Log)
page 40
2008 Foundation Series Fire Alarm Control Unit Operation Guide
Table 16: Logs contents
Stored events
Alarms
Alarm acknowledge
Log cleared
Alarm silence
System reset
Supervisory conditions
Supervisory acknowledge
Log cleared
Trouble events
Log cleared
WALK TEST events
HW reset
Login events for level 2 or higher
Logout events for manual and auto logout
Invalid login attempts - for incorrect password entry
Log cleared
All events in chronological order
579-1401 Rev A
