Simplex Foundation Series Operation Manual page 44

4. Use the UP or DOWN keys to choose one of the options:
- IDC
- Relay
- NAC
- System
Note: You can use system points for viewing only, but you can not control the system points.
5. Press ENTER to select the appropriate point category. The control unit displays the following:
IDC1
Fire NORMAL
Use the UP or DOWN keys to scroll through the list of points in the selected category.
6.
7. Press ENTER to view the status of the selected point. The hardware type and function type for the point are shown similar to the
following example:
IDC1
Fire NORMAL M1
Additional information and control options are available as described in Table 17.
Function Description
1. Press ENTER to view the point's hardware type and assigned function type. For example:
IDC
IDC1
BZONE
2. Press the DOWN key to view the following information for the IDC:
- Enable and disable status
- Alarm verification tally
- Electrical state (normal, short, open, abnormal)
- Assigned alarm groups
1. Press ENTER to view the point's hardware type and assigned function type. For example:
NAC
NAC1
NAC
2. Press the DOWN key to view the following information for the point.
- Electrical State (open/short/normal)
- Enable and disable status
- Output state (on/off/coding)
- Function type and output method
- Assigned alarm groups
System point 1. Press ENTER to view a description of the first system point in the list.
2. Press DOWN to scroll through the list of points.
page 42
Table 17: Additional point information
FIRE
2008 Foundation Series Fire Alarm Control Unit Operation Guide
579-1401 Rev A
