9.4.7

Setting the test report time

This option specifies the time at which the Test Report Event is sent to the supervising station. Time is set in 24 hour, military format.
For system software revision 01.00 and later, the test report message is sent at six hour intervals beginning at the time entered.
To set the report time, complete the following steps:
1. See the Accessing the DACT program menu
2. Press ENTER and then press the UP and DOWN keys until [Test Rpt Time] is displayed.
<ENTER>=Accept
Opt: [Test Rpt Time]
3. Press ENTER. The control unit displays the following:
Test Rpt Time
[02]:00
Use the UP and DOWN keys to decrement or increment the hour setting, the two digits on left.
4.
5. Use the RIGHT key to move the cursor to the minutes, the two digits on the right. Use UP and DOWN keys to decrement or
increment the minutes setting.
6. Press ENTER to accept the choice. The prompt shown in Step 2 reappears.
7. Press ENTER.
Press the DOWN key to move to next option [AC Fail Delay].
8.
9.4.8

Setting the AC fail delay

To set the AC fail delay, complete the following steps:
1. See the Accessing the DACT program menu
Press ENTER and then press the UP and DOWN keys until [AC Fail Delay] is displayed.
2.
<ENTER>=Accept
Opt: [AC Fail Delay]
3. Press ENTER. The control unit displays the following:
AC Fail Delay
[02] Hrs
4. Use the UP and DOWN keys to scroll through the choices.
5. Press ENTER to accept the choice. The prompt shown in Step 2 reappears.
Press ENTER.
6.
Press the DOWN key to move to next option [IP COMMUNICATR].
7.
9.4.9

Selecting the IP communicator

With this option, you can choose between IP communicator and PSTN line connection for DACT.
To select the IP communicator, use the following steps:
1. See the Accessing the DACT program menu
Press ENTER and then press the UP and DOWN keys until [IP COMMUNICATOR] is displayed.
2.
<ENTER>=Accept
Opt: [IP COMMUNICATOR]
3. Press ENTER. The control unit displays the following:
IP COMMUNICATOR
[NORMAL 2 LINES]
4. Use the UP and DOWN keys to scroll through the choices.
Press ENTER to accept the choice. The prompt shown in Step 2 reappears.
5.
Press ENTER.
6.
page 33
2008 Foundation Series Fire Alarm Control Unit Operation Guide
section and repeat the steps from 1 to 4.
