Reporting CID points

The CID reporting format requires you to specify the group and Contact ID for each point. There is no need to specify the type of event
with the CID format, this information is automatically derived from the point's function type. See Table 14 for default CID event codes.
Note: Default CID point values are provided in the control unit. Before changing these values, contact an authorized representative at the
supervising station.
To select the reporting points, complete the following steps:
1. See the Accessing the DACT program menu
2. Press ENTER and then use the UP and DOWN keys until [CID POINTS] is displayed.
<ENTER>=Accept
DACT: [CID POINTS]
3. Press ENTER. The control unit displays the following:
[Garage IDC1]
[GRP:01 ID:001]
This prompt consists of the following fields:
- Point Custom Label: The top line of the prompt displays the custom label assigned to the point.
- Grp: Two-digit number used to group associated devices together.
- ID (Contact ID): Three-digit number used to identify a specific point and device.
4. For each point, use the RIGHT key to move between the digits of the GRP and ID fields. Use the UP and DOWN keys to
increment or decrement the value of a digit.
5. To choose another point, press the RIGHT key until the cursor is on the top line (custom label) of the prompt. Use the UP and
DOWN keys to scroll to another point and then repeat Step 4.
6. When all points have been configured press ENTER. The control unit displays the following prompt:
<ENTER>=Confirm
GRP: 01 ID: 001
Press ENTER. The prompt shown in Step 2 reappears.
7.
When DACT programming is complete, press ESC key until the control unit displays the following prompt:
8.
[Cont] Dscrd Save
Select [Save] and press ENTER to save the configuration.
9.
Description
IDC 1 through IDC 8
NAC 1
NAC 2
Aux Relay 1
Aux Relay 2
Aux Relay 3
Aux Relay 4
AC Power
Aux Power
Positive Earth Fault
Negative Earth Fault
Low Battery
Battery Depleted
Low Battery Cutout
Charger Trouble
Manual Test Report
DACT Phone Line 1 Trouble
DACT Phone Line 2 Trouble
6 hr Test Report
page 34
2008 Foundation Series Fire Alarm Control Unit Operation Guide
section and repeat the steps from 1 to 4.
Table 14: CID points default values
CID points
GRP:01 ID:001 through GRP:01 ID:008
GRP:01 ID:201
GRP:01 ID:202
GRP:01 ID:203
GRP:01 ID:204
GRP:01 ID:205
GRP:01 ID:206
GRP:01 ID:207
GRP:01 ID:208
GRP:01 ID:209
GRP:01 ID:210
GRP:01 ID:211
GRP:01 ID:212
GRP:01 ID:213
GRP:01 ID:214
GRP:01 ID:233
GRP:01 ID:233
GRP:01 ID:234
GRP:01 ID:235
Event code
Based on device function type
*
*
*
*
*
*
Trouble 301
Trouble
Trouble 310
Trouble 310
Trouble 302
Trouble
Trouble
Trouble
Test 601
Trouble 351
Trouble 352
Test 602
579-1401 Rev A
